Vishay Shielded Surface Mount Inductor 22μH ±20% Metal Composite Core 1.9A Idc 2020 Package IHLP2020CZER220M11
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 3mm |
| Length | 5.49mm |
| Model | IHLP2020CZER220M11 |
| Depth | 3mm |
| Series | IHLP-2020CZ-11 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 22μH |
| Package/Case | 2020 |
| Maximum DC Current | 1.9A |
| Maximum DC Resistance | 270mΩ |
| Inductance Tolerance | ±20 % |
| Maximum Self Resonant Frequency | 10.7MHz |
| Inductor Construction | Shielded |
Key Features
- Designed for high current, low profile surface mount applications.
- Features a metal composite core that provides high efficiency and low buzz noise.
- Capable of handling transient current spikes without saturation.
- Inductance tolerance is ±20%, suitable for robust electronic circuits.
- Operating temperature range from -55°C to 125°C for diverse environments.
- Package size 2020 with dimensions 5.49mm length, 3mm depth, and 3mm height.
- Maximum DC resistance of 270 milliohms ensuring low power loss.
- Maximum self-resonant frequency is 10.7 MHz, suitable for frequency ranges up to 1 MHz.
Product Description
Vishay IHLP2020CZER220M11 is a shielded surface mount inductor designed for electronic components requiring high current handling and low profile design. This inductor uses a metal composite core for improved efficiency and reduced noise. With an inductance value of 22μH and a tolerance of ±20%, it is optimized to operate at currents up to 1.9 A DC, suitable for sensitive and high-performance electrical applications.
Its compact 2020 package measures 5.49mm in length, 3mm in width, and 3mm in height, making it ideal for space-constrained PCBs. The device operates reliably across a temperature range from -55°C to 125°C, ensuring stability in harsh and variable environments common in industrial, power management, telecommunications, and computing equipment.
The inductor construction is shielded to minimize electromagnetic interference, offering better performance in mixed-signal circuits. It features a maximum DC resistance of 270mΩ which reduces power loss and heat generation for efficient power conversion. Its maximum self-resonant frequency of 10.7 MHz enables operation in high-frequency switching applications.
Typical use cases include power on logic (POL) converters, distributed power systems, DC/DC converters for FPGA platforms, and battery-powered portable devices. Its robustness against transient current spikes and low audible noise make it suitable for high-reliability industrial and commercial electronics sectors.
Designed for high current, low profile mounting on PCBs. Metal composite core ensures low noise and high efficiency. Handles transient current spikes without magnetic saturation. Wide operating temperature range from -55°C to 125°C.
Low DC resistance reduces power loss. Shielded construction minimizes electromagnetic interference. Compact dimensions fit in space-restricted applications. Maximum self-resonant frequency of 10.7 MHz supports high-frequency circuits.
Ideal for power conversion, battery powered devices, and FPGAs.
This Vishay surface mount inductor is an essential component in electronic manufacturing requiring efficient power management solutions. Browse more Surface Mount Inductors and related components at EnvMart to find the right part for your industrial and commercial electronics projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 22μH with a tolerance of ±20%.
It can handle a maximum DC current of 1.9A.
The package size is 2020, with dimensions of 5.49mm in length, 3mm in depth, and 3mm in height.
The maximum self-resonant frequency is 10.7 MHz.
It operates reliably within a temperature range from -55°C to 125°C.
The core material is metal composite, which provides high efficiency and low noise.
The shielded construction minimizes electromagnetic interference, enhancing performance in mixed-signal circuits.
The maximum DC resistance is 270 milliohms, which helps reduce power loss.
It is suitable for applications such as power on logic converters, distributed power systems, and DC/DC converters for FPGA platforms.
This inductor belongs to the IHLP-2020CZ-11 series.
The inductance tolerance of ±20% ensures that it can be used in robust electronic circuits without significant deviation from the specified inductance value.
The country of origin for this inductor is India.
