Nexperia Transistor 1 A NPN Bipolar 60 V 4-Pin UPAK Surface Mount BCX55-16,115

Nexperia BCX55-16,115 is a general purpose NPN bipolar transistor designed for surface mounting in a compact 4-pin UPAK package. It supports a maximum DC collector current of 1 ampere and collector-emitter voltage of 60 volts, making it suitable for a wide range of electronic applications requiring reliable switching and amplification.

The device features a minimum DC current gain (hFE) of 63 and a maximum transition frequency (ft) of 180 MHz, ensuring adequate performance in RF and signal processing circuits. It withstands power dissipation up to 1.25 watts with a maximum operating temperature of 150°C, and a minimum operating temperature rating of -55°C for harsh environments.

Physical dimensions include a length of 4.6 mm, width of 2.6 mm, and height of 1.5 mm, allowing easy integration in compact circuit designs. This transistor adheres to RoHS environmental standards and automotive qualification AEC-Q101, underscoring its reliability in automotive and industrial contexts.

The 4-pin UPAK surface mount package ensures sturdy mechanical and electrical connectivity to printed circuit boards, making it ideal for use in industrial controllers, power management systems, and general electronic circuit assemblies.

This transistor has a maximum collector current of 1 ampere. Operates with a collector-emitter voltage up to 60 volts. Capable of dissipating 1.25 watts of power reliably. Minimum DC current gain of 63 enhances performance in amplification circuits.

High-frequency operation up to 180 MHz supported. Temperature range suits automotive and industrial applications (-55°C to 150°C). Compliant with RoHS and automotive standard AEC-Q101 regulations.

This product is suitable for industrial, automotive, electronic manufacturing, and laboratory applications requiring durable and efficient NPN bipolar transistors. Explore more Bipolar Transistors and semiconductors at EnvMart for comprehensive electronic component solutions.
