Molex 95522 Series RJ45 Connector Female, Through Hole Mount, Cat3 Unshielded Vertical 2 Port 1 Way RJ45

Molex RJ45 RJ45 Connector Female, Through Hole Mount, Cat3 Unshielded Vertical 2 Port 1 Way Ethernet Connector is engineered for use in electronic, industrial, and networking equipment to facilitate reliable data transmission at Category 3 standards.

The connector features a female RJ45 interface with two ports and a single way, designed for through hole mounting on PCBs. Its copper alloy contacts with gold over nickel plating ensure excellent electrical conductivity and long-lasting corrosion resistance, vital for maintaining signal integrity in harsh operating environments.

Its vertical orientation and compact dimensions (16.64 mm length, 15.24 mm width, and 16.25 mm depth) provide a high profile and robust footprint suitable for various industrial and communication hardware designs. The connector does not support shielding or magnetic elements, focusing on straightforward, cost-effective designs where unshielded connectors suffice.

Operating temperature ranges from -40° to 85°C ensure the device performs reliably in demanding temperature conditions common in industrial and commercial networking systems. The solder termination type facilitates secure mechanical and electrical attachment, supporting both traditional soldering and surface-mount technologies.

This connector series is part of Molex's 95522 line, known for high quality and adherence to industry standards for Ethernet connectivity. It is designed specifically for applications such as network switches, routers, telecommunications devices, and industrial control systems where reliable Cat3 unshielded Ethernet connections are required.

The connector supports Cat3 unshielded vertical configuration with two ports. Features a female RJ45 interface with through hole mount technology for secure PCB installation. Constructed with copper alloy contacts plated gold over nickel for excellent conductivity and corrosion resistance.

Operates efficiently within a temperature range of -40°C to 85°C, suitable for varied environments. Compact dimensions with a length of 16.64 mm, width of 15.24 mm, and depth of 16.25 mm enable integration into space-limited applications.

Provides a high profile vertical mount with ribbed housing and industry-standard footprint. Designed without shielding or magnetic components, emphasizing simplicity and ease of solder termination. Compatible with solder termination and SMT processes, enhancing manufacturing flexibility.

Maintains stable performance in industrial, networking, and telecommunications equipment applications.

Choose Molex 95522 Series RJ45 Connector for dependable Cat3 Ethernet connectivity in industrial and commercial networking applications. Browse additional Ethernet Connectors in EnvMart for complete network infrastructure solutions.
