Vishay 90 F Electric Double Layer Supercapacitor 4.2V DC 196 HVC Series Through Hole MAL219690101E3

Vishay MAL219690101E3 is a high-capacitance 90 F electric double layer supercapacitor designed for energy storage applications requiring high current and rapid charge/discharge cycles. This supercapacitor is part of the 196 HVC series and supports a maximum operating voltage of 4.2 V DC. Its through hole mounting type with radial terminal pins and a 10 mm pin pitch allows for secure PCB integration in electronic devices.

The device includes a precision polar capacitor design with a low equivalent series resistance (ESR) of 135 mΩ which enhances energy efficiency and reduces heat generation during operation. It supports a broad operating temperature range from -20°C to 85°C with a rated lifetime of approximately 1000 hours at maximum temperature conditions, making it suitable for industrial, automotive electronics, backup power supplies, energy harvesting, and real-time clock applications.

The supercapacitor measures 12 mm in diameter, 10 mm in height, and 35 mm in depth, fitting compactly within electronic assemblies. The leakage current is maintained at a low 500 μA, helping to preserve stored energy during idle periods. The component is RoHS-compliant, ensuring it meets current safety and environmental regulations.

Capacitance of 90 Farads for high energy storage capacity. Low ESR of 135 milliohms for efficient charge/discharge cycles. Radial terminal type with through hole mount ensures robust mechanical and electrical connections.

Wide operating temperature range suitable for diverse industrial environments. 1000-hour lifetime at 85°C allows long-term application use. RoHS compliant and supplied in ESD tray packaging for safe handling.

This Vishay supercapacitor is ideal for use in power backup systems, embedded computing devices, data storage systems, emergency lighting, gaming machines, and networking equipment where reliable energy storage and rapid charge cycles are critical. It supports new designs requiring high energy density components with robust lifespan and environmental compliance.
