Wurth Elektronik WE-MAPI 3020 Shielded Wirewound Surface Mount Inductor Magnetic Iron Alloy Core 0.47μH ±30% 744383360047
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2mm |
| Length | 3mm |
| Depth | 3mm |
| Packaging | Tape & Reel |
| Series | WE-MAPI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Magnetic Iron Alloy |
| Inductance | 0.47μH |
| Standards/Approvals | IEC 61249-2-21, JEDEC JS709B, REACH, RoHS |
| Package/Case | 3020 |
| Maximum DC Current | 4.8A |
| Maximum DC Resistance | 22mΩ |
| Inductance Tolerance | ±30 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 99MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Features a compact 3020 package suitable for efficient PCB mounting.
- Supports a maximum DC current of 4.8 A with a maximum DC resistance of 22 mΩ.
- Designed to operate over a temperature range from -40°C to 125°C.
- Magnetically shielded construction reduces acoustic and leakage flux noise during operation.
- Meets automotive standard AEC-Q200 and has IEC 61249-2-21, JEDEC JS709B, REACH, and RoHS compliances.
- Maximum self-resonant frequency is specified at 99 MHz.
- Termination style is surface mount suitable for automated assembly processes.
- Core material is magnetic iron alloy for high transient current handling capability.
Product Description
Wurth Elektronik 744383360047 WE-MAPI 3020 series is a shielded wirewound surface mount inductor with a magnetic iron alloy core offering an inductance of 0.47 μH with ±30% tolerance. This inductor is designed for high performance in DC/DC converters, power supplies, and portable electronic devices.
Its compact 3020 package and shielded construction provide excellent noise reduction and high transient current handling. The inductor supports a maximum DC current of 4.8 A and operates reliably from -40°C to 125°C, making it suitable for demanding automotive and industrial environments.
The magnetic iron alloy core construction ensures low acoustic noise and minimal leakage flux, improving efficiency and system stability. The product meets various standards and approvals including AEC-Q200, IEC 61249-2-21, JEDEC JS709B, REACH, and RoHS, verifying its robust quality and environmental compliance.
Key attributes include a maximum DC resistance of 22 mΩ, a self-resonant frequency up to 99 MHz, and molded wirewound construction for durability. Terminations are surface mount style, designed for seamless PCB integration, and packaging in tape and reel format supports automated assembly lines.
This inductor is ideal for applications such as DC/DC converters, FPGA power supplies, POL converters, portable power devices such as PDAs and digital cameras, mainboards, graphic cards, battery-powered devices, wireless communications, and smartphone power supplies.
Compact 3020 package with shielded wirewound construction. Magnetic iron alloy core for high current transient handling. Wide operating temperature range from -40°C to 125°C. Low acoustic noise and leakage flux noise performance.
Compliance with automotive and international quality standards. Tape and reel packaging for efficient manufacturing use. Explore the Surface Mount Inductors category for more high-quality power inductors suitable for industrial, automotive, and electronics manufacturing use cases on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 0.47μH with a tolerance of ±30%.
It supports a maximum DC current of 4.8 A.
The dimensions of this inductor are 3mm in length, 3mm in depth, and 2mm in height.
The maximum operating temperature is 125°C.
The core material is a magnetic iron alloy, which enhances transient current handling capability.
The maximum self-resonant frequency is specified at 99 MHz.
It meets automotive standard AEC-Q200 and complies with IEC 61249-2-21, JEDEC JS709B, REACH, and RoHS.
The termination style is surface mount, suitable for automated assembly processes.
The maximum DC resistance is 22 mΩ.
This inductor is suitable for applications such as DC/DC converters, power supplies, and portable electronic devices.
It is packaged in tape and reel format, which supports efficient manufacturing processes.
The construction type of this inductor is wirewound, which contributes to its performance characteristics.
