Broadcom Optocoupler, Through Hole, 8-Pin DIP, 1 Channel, 230mA Input Current, 3750Vrms Isolation Voltage HCPL-2211-000E
Specifications
| Country of Origin | India |
|---|---|
| Brand | Broadcom |
| Model | HCPL-2211-000E |
| Packaging | Tape & Reel |
| Mount Type | Through Hole |
| Series | HCPL |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 230mA |
| Number Of Channels | 1 |
| Standards/Approvals | UL 1577, IEC/EN/DIN EN 60747-5-2, CSA |
| Maximum Forward Voltage | 1.85V |
| Number of Pins | 8 |
| Typical Rise Time | 30ns |
| Typical Fall Time | 7ns |
| Broadcom HCPL-0201-000E DC Input Optocoupler, Surface, 8-Pin SOICBrand | Broadcom |
| Broadcom HCNW2211-000E DC Input Optocoupler, Through Hole, 8-Pin DIPBrand | Broadcom |
Key Features
- Supports a maximum input current of 230mA.
- Designed for operating temperatures from -40°C to 85°C.
- Typical rise time is 30ns and fall time is 7ns.
- Complies with UL 1577, IEC/EN/DIN EN 60747-5-2, and CSA standards.
- Packaged on tape and reel for easy automated assembly.
- Logic output type ensures compatibility with digital circuits.
- Suitable for industrial and electronic component applications.
Product Description
Broadcom HCPL-2211-000E is a through hole mount optocoupler supplied in an 8-pin DIP package, featuring a single channel logic output. It supports a maximum input current of 230mA with an isolation voltage of 3750Vrms, making it suitable for industrial isolation applications.
The device operates reliably within a temperature range from -40°C to 85°C, making it adaptable to harsh operating conditions. It offers fast switching with a typical rise time of 30ns and fall time of 7ns, ideal for precision electronic controls.
Certified to meet UL 1577, IEC/EN/DIN EN 60747-5-2, and CSA standards, the HCPL-2211-000E ensures compliance with safety and quality requirements for electronic components. The device is delivered on tape and reel packaging, facilitating efficient assembly in manufacturing environments.
Common applications include industrial automation, electronic isolation, and interfacing between high voltage and low voltage circuits. The logic output type enables direct interfacing with digital systems for reliable signal transmission.
Supports a maximum input current of 230mA. Operating temperature range from -40°C to 85°C. Typical rise time of 30ns and fall time of 7ns. Designed for high isolation voltage of 3750Vrms. Complies with multiple safety and quality standards.
Packaged in 8-pin DIP through hole mount format. Logic output suitable for digital interfacing. Explore our extensive range of electronic components and Optocouplers at EnvMart for your industrial and laboratory needs.
