Broadcom 3 V White LED 0603 Surface Mount Package ASMT-CW20
Specifications
| Country of Origin | China |
|---|---|
| Brand | Broadcom |
| Model | ASMT-CW20 |
| Packaging | Tape & Reel |
| Mount Type | Surface |
| Number Of Leds | 1 |
| Maximum forward current | 10mA |
| Viewing angle | 130 ° |
| Package Type | 0603 |
| Standards/Approvals | RoHS |
| LED Colour | White |
| Forward Voltage | 3V |
| Number of Pins | 2 |
| LED Luminosity | 180 mcd |
| Maximum Power Dissipation | 32mW |
| Lens Dimensions | 1.6 x 0.8 x 0.2 mm |
| Lens Shape | Rectangular |
Key Features
- The LED emits high brightness white light with 180 millicandela luminosity.
- It features a compact 0603 surface mount package suitable for dense PCB layouts.
- Maximum forward current is 10mA, allowing conservative current use.
- Designed for tape and reel packaging, facilitating automated assembly.
- The clear rectangular lens ensures broad directional light distribution.
- Energy-efficient with only 32mW maximum power dissipation to reduce thermal load.
- Operates at a nominal forward voltage of 3V for low voltage drive circuits.
- Compliant with RoHS standards restricting hazardous substances.
Product Description
Broadcom ASMT-CW20 is a high-quality 3 V white LED designed for surface mounting on compact electronic assemblies. Its 0603 package size (1.6 x 0.8 x 0.2 mm lens dimensions) allows for dense placement on printed circuit boards while delivering efficient illumination with minimal thermal impact.
This LED emits a luminous intensity of 180 mcd through a clear rectangular lens with a wide 130° viewing angle, making it suitable for various indicator and backlighting applications. The device operates at a maximum forward current of 10 mA and has a forward voltage of 3 V, supporting straightforward, low-voltage LED driver circuits.
The product is packaged in tape and reel format, optimized for automated pick-and-place assembly processes in manufacturing environments. Compliance with RoHS ensures it meets environmental safety standards by restricting hazardous materials.
Typical applications include status indication on handheld instruments, backlighting for small control panels and keypads, integration with compact sensor modules for visible signaling, and visual alerts in automotive-adjacent electronics and portable devices with stringent power requirements.
The LED outputs 180 mcd white light for clear visibility. Compact 0603 surface mount footprint facilitates high-density PCB layout. Maximum forward current of 10 mA conserves energy use. 3 V forward voltage enables simple, low-voltage drive solutions.
Clear rectangular lens provides a wide 130° viewing angle. Maximum power dissipation of 32 mW reduces heat generation. RoHS compliant for environmental safety and hazardous substance restrictions. Suitable for use in industrial, automotive-adjacent, and consumer electronics applications.
Choose this Broadcom ASMT-CW20 LED for precise, reliable, and efficient light output in demanding electronic equipment manufacturing and prototyping use cases. EnvMart offers this trusted component for seamless integration into your LED indicator and lighting designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ASMT-CW20 LED emits a luminous intensity of 180 millicandela (mcd).
This model operates at a nominal forward voltage of 3V, suitable for low voltage drive circuits.
The maximum forward current for this LED is 10mA, allowing for conservative current use.
The LED features a wide viewing angle of 130°, providing broad directional light distribution.
The lens dimensions of the ASMT-CW20 are 1.6 x 0.8 x 0.2 mm.
This LED is packaged in tape and reel format, facilitating automated assembly processes.
The maximum power dissipation for the ASMT-CW20 is 32mW, which helps reduce thermal load.
It uses a surface mount type, which is suitable for dense PCB layouts.
Yes, it is compliant with RoHS standards, which restrict hazardous substances.
This LED is suitable for status indication on handheld instruments, backlighting for control panels, and visual alerts in electronics.
The ASMT-CW20 package includes one LED.
This model emits high brightness white light.
