3M WR-PHD Series Straight Through Hole Pin Header 16 Contacts 1.27 mm Pitch 2 Row Unshrouded 62201621121

Free Delivery in India | Lowest Global Shipping Charges

3M WR-PHD Series Straight Through Hole Pin Header 16 Contacts 1.27 mm Pitch 2 Row Unshrouded 62201621121



Category PCB Headers Brand 3M Condition New

Specifications

Country of Origin	India
Voltage	50V
Brand	3M
Orientation	Straight
Current	1A
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Copper Alloy
Series	WR-PHD
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	16
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Tail Pin Length	2.3mm
Mating Pin Length	3.81mm

Key Features

The pin header features 16 male contacts for robust electrical connections.
It uses a 1.27 mm pitch with a dual row configuration for compact PCB design.
The housing is made from polyamide with black UL94-V0 PA6T insulation for high thermal resistance.
Contacts are stamped from a copper alloy and plated with gold for corrosion resistance and conductivity.
Designed for through hole mounting ensuring secure mechanical stability.
Operating temperature range spans from -40°C to 125°C for versatile environmental conditions.
Mating pin length is 3.81 mm and tail pin length is 2.3 mm to meet precise assembly requirements.

Product Description

Wurth Elektronik 62201621121 WR-PHD Series straight through hole pin header features 16 male contacts arranged in 2 rows with a 1.27 mm pitch, designed for secure board-to-board connections in various electronic applications. Operating at 50V and 1A current, this component is ideal for reliable signal connection in low power circuits used in industrial, electronic manufacturing, and laboratory equipment.

The housing utilizes a black polyamide UL94-V0 PA6T insulator providing excellent flame retardancy and durability in high temperature environments ranging from -40°C to 125°C. The copper alloy contacts are gold-plated to ensure optimal conductivity and corrosion resistance. The connector is unshrouded and designed for through hole mounting, yielding robust mechanical hold and easy soldering integration.

This component is engineered to meet board-to-board connection needs with precise mating pin length of 3.81 mm and tail pin length of 2.3 mm, ensuring compatibility and ease of installation in dense PCB layouts.

The pin header provides 16 male contacts for reliable electrical connection. Dual row design with 1.27 mm pitch optimizes PCB space usage. Polyamide housing with flame retardant properties ensures safety and durability. Gold-plated copper alloy contacts provide superior conductivity and corrosion resistance.

The through hole mounting type ensures sturdy mechanical fixation on PCBs. Operating voltage and current ratings of 50V and 1A suit low power applications. Wide operating temperature range from -40°C to 125°C supports diverse environmental conditions.

Unshrouded design facilitates easy mating with corresponding connectors.

Commonly used in industrial, electronic manufacturing, laboratory, and commercial electronic assemblies, this WR-PHD series pin header from Wurth Elektronik supports precise, rugged, and reliable connections essential for modern PCB designs.
