Vishay Single Layer Ceramic Capacitor 680 pF 440V AC ±20% Y5U Dielectric Through Hole Radial 125°C Max AY2681M29Y5US63L7

Vishay AY2681M29Y5US63L7 is a single layer ceramic capacitor designed for AC line rated applications, featuring a 680 pF capacitance and a voltage rating of 440V AC. Its ±20% tolerance and Y5U dielectric material provide stable capacitance characteristics for various industrial and electronic uses.

This capacitor is a through hole type with radial terminals facilitating easy and reliable mounting on printed circuit boards. It withstands operating temperatures up to 125°C, making it suitable for high-temperature environments commonly found in automotive electronics, industrial machinery, and power electronics.

The capacitor dimensions are 10.5mm in height, 7.5mm in diameter, and 5mm in length and width, offering a compact form factor for space-constrained designs. With a dissipation factor of 2.5%, it delivers low energy losses, enhancing overall system efficiency.

Certified for standards such as EC and RoHS, this capacitor adheres to environmental and industry requirements. Its suppression class Y2/X1 rating and compliance with IEC 60384-14 ensure safety and reliability in AC line filtering and noise suppression tasks.

Applications extend to onboard chargers and battery management systems in electric and hybrid vehicles, industrial automation systems, and other high-reliability environments requiring durable ceramic capacitors.

Constructed with Y5U dielectric material suitable for AC line applications. Through hole mount type with radial terminal for secure PCB installation. Maximum operating temperature of 125°C ensuring reliable performance under thermal stress.

Compact dimensions including 10.5mm height and 7.5mm diameter form factor. Complies with IEC 60384-14 safety standards and RoHS directive for environmental compliance. Low dissipation factor of 2.5% minimizing energy loss during AC operation.

Pin count of 2 suitable for standard capacitor circuits. Designed for industrial, automotive, and electronic component applications requiring AC line filtering.

Choose Vishay Single Layer Ceramic Capacitors for robust, high-quality components suitable for demanding electronic and automotive applications. Explore more capacitors and components in the Electronics Components category at EnvMart.
