Infineon PIN Diode 100 mA 150 V Surface Mount SOT-323 Package 3-Pin BAR6404WH6327XTSA1

Free Delivery in India | Lowest Global Shipping Charges

Infineon PIN Diode 100 mA 150 V Surface Mount SOT-323 Package 3-Pin BAR6404WH6327XTSA1

Name: Infineon PIN Diode 100 mA 150 V Surface Mount SOT-323 Package 3-Pin BAR6404WH6327XTSA1
Brand: Infineon
SKU: 378841
Price: 0.14 USD
Availability: InStock



Category PIN Diodes Brand Infineon Condition New

Specifications

Country of Origin	India
Brand	Infineon
Height	0.8mm
Length	2mm
Model	BAR6404WH6327XTSA1
Mount Type	Surface
Series	BAR64
Maximum Operating Temperature	125°C
Package Type	SOT-323
Minimum Operating Temperature	-55°C
Standards/Approvals	Pb-Free (RoHS)
Pin Count	3
Automotive Standard	AEC-Q101
Diode Configuration	Series
Maximum Forward Voltage Vf	1.1V
Maximum Forward Current If	100mA
Maximum Capacitance	0.35pF
Maximum Reverse Voltage Vr	150V
Maximum Series Resistance @ Maximum If	20Ω

Key Features

Designed for use in RF switching and attenuator circuits.
Maximum capacitance of 0.35 pF enhances high-frequency performance.
Low maximum series resistance of 20 ohms at maximum forward current.
Maximum forward voltage of 1.1 V ensures efficient operation.
Operating temperature range from -55°C to 125°C for reliability in harsh environments.
Compact dimensions of 2 mm length and 0.8 mm height optimize PCB space.
Compliance with Pb-Free (RoHS) standards ensures environmental safety.
Automotive standard AEC-Q101 qualified for high reliability applications.

Product Description

Infineon BAR6404WH6327XTSA1 is a high-performance PIN diode designed for electronic applications requiring reliable fast switching and signal attenuation at RF frequencies. This diode features a maximum forward current of 100 mA and a reverse voltage rating of 150 V, suitable for demanding semiconductor circuits.

The device is configured in series diode configuration housed in a compact 3-pin SOT-323 surface mount package. Its maximum capacitance of 0.35 pF allows for minimal parasitic effects, improving signal integrity at high frequencies.

Its low series resistance of 20 ohms at maximum forward current and maximum forward voltage of 1.1 V supports efficient circuit operation. The diode performs reliably within an extended temperature range from -55°C to 125°C, making it ideal for automotive and industrial environments.

With dimensions of 2 mm length and 0.8 mm height, the BAR6404WH6327XTSA1 is optimized for space-constrained PCBs. It complies with Pb-Free (RoHS) regulations and meets the rigorous AEC-Q101 automotive qualification standard, ensuring durability and compliance for automotive electronics applications.

This PIN diode is ideal for RF switching, attenuator circuits, and other semiconductor discrete component applications in industrial, automotive, and consumer electronics sectors. Designed for use in RF switching and attenuator circuits.

Maximum capacitance of 0.35 pF enhances high-frequency performance. Low maximum series resistance of 20 ohms at maximum forward current. Maximum forward voltage of 1.1 V ensures efficient operation. Operating temperature range from -55°C to 125°C for reliability in harsh environments.

Compact dimensions of 2 mm length and 0.8 mm height optimize PCB space. Compliance with Pb-Free (RoHS) standards ensures environmental safety. Automotive standard AEC-Q101 qualified for high reliability applications. Explore more Infineon PIN Diodes and semiconductor components on EnvMart for your industrial and automotive electronic needs.
