NXP Single PIN Diode, 2-Pin UMD Surface Mount, 100 mA Forward Current, 30 V Reverse Voltage BAP65-03,115
Specifications
| Country of Origin | China |
|---|---|
| Brand | NXP |
| Height | 1.05mm |
| Length | 1.8mm |
| Model | BAP65-03,115 |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | UMD |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Maximum Forward Voltage Vf | 1.1V |
| Maximum Forward Current If | 100mA |
| Maximum Capacitance | 0.8pF |
| Maximum Reverse Voltage Vr | 30V |
| Maximum Series Resistance @ Maximum If | 0.9Ω |
Key Features
- This diode has a single diode configuration suitable for RF switching and attenuator applications.
- The maximum capacitance is low at 0.8 pF, aiding in high frequency performance.
- Surface mount design with a UMD package type and 2 pins facilitates compact PCB layouts.
- Maximum series resistance at rated forward current is 0.9 ohms, ensuring efficient conduction.
- Forward voltage drop is a maximum of 1.1 V, minimizing power loss during operation.
- Operational temperature range spans from -65°C to 150°C, enabling use in diverse environmental conditions.
- The diode complies with Automotive Standard AEC-Q101, ensuring reliability for automotive use.
- Physical dimensions include a length of 1.8 mm and height of 1.05 mm, ideal for compact designs.
Product Description
The NXP BAP65-03,115 is a single PIN diode designed for surface mount applications with a 2-pin UMD package. It supports a maximum forward current of 100 mA and can withstand a maximum reverse voltage of 30 V. Its low capacitance of 0.8 pF makes it suitable for high-frequency RF switching and attenuator circuits commonly found in communications and automotive industries.
This diode features a maximum forward voltage of 1.1 V and maximum series resistance of 0.9 ohms at rated forward current, which allows efficient signal transmission with minimal losses. It has a robust operational temperature range from -65°C to 150°C, making it highly reliable under extreme conditions.
The device meets the automotive standard AEC-Q101, endorsing it for use in automotive electronics where quality and durability are critical. Its compact dimensions of 1.8 mm length and 1.05 mm height aid in space-sensitive PCB designs.
With its surface mount compatibility, the BAP65-03,115 diode is ideal for RF applications, communications equipment, and automotive electronics requiring dependable switching components.
Single diode configuration designed for RF switching use. Compact 2-pin UMD surface mount packaging. Maximum forward current rating of 100 mA ensures sufficient handling capacity. Low capacitance of 0.8 pF supports high-frequency performance.
Wide operating temperature range from -65°C to 150°C for harsh environments. Meets automotive standard AEC-Q101 for high reliability. Forward voltage drop limited to 1.1 V for energy efficiency. Compact 1.8 mm length and 1.05 mm height for space-efficient mounting.
This NXP PIN diode is suitable for industrial, automotive, and communications applications where reliable RF switching and signal attenuation are required. Explore more semiconductor components on EnvMart for your engineering and manufacturing needs.
Explore more products in our PIN Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward current of the BAP65-03,115 diode is 100 mA.
It can withstand a maximum reverse voltage of 30 V.
The maximum capacitance of this diode is 0.8 pF, which aids in high-frequency performance.
The maximum forward voltage drop is limited to 1.1 V.
The diode has a length of 1.8 mm and a height of 1.05 mm, making it suitable for compact PCB designs.
It operates within a temperature range of -65°C to 150°C.
This model uses a UMD package type for surface mount applications.
Yes, it complies with the Automotive Standard AEC-Q101, ensuring reliability for automotive use.
The maximum series resistance at the rated forward current is 0.9 ohms.
This diode is suitable for RF switching and attenuator applications in communications and automotive industries.
The BAP65-03,115 has a 2-pin configuration.
The diode is manufactured by NXP.
