Texas Instruments PLL Circuit 1 Output 16-Pin 5.5V PDIP CD74HCT7046AE

Texas Instruments CD74HCT7046AE is a Phase Locked Loop (PLL) circuit from the CD74HC CMOS logic family, designed for high-speed clock synthesis and timing applications.

This device features a single output and operates within a supply voltage range of 4.5 V to 5.5 V, delivering high-performance with low power consumption thanks to the CMOS technology.

The IC package is a 16-pin Dual Inline Package (PDIP), suitable for through-hole mounting on printed circuit boards in industrial, laboratory, and electronic manufacturing applications.

The maximum output frequency is 18 MHz, and it supports input frequencies up to 12 MHz, ensuring flexibility in timing and clock generation tasks. It is compatible with TTL inputs and provides CMOS output logic levels, ensuring interoperability with a wide range of digital logic families.

The device withstands temperature ranges from -55°C to 125°C, making it reliable for harsh environments and automotive-grade applications, although it does not conform to specific automotive standards.

The compact size of 19.3 mm length, 6.35 mm width, and 4.57 mm height allows integration into space-constrained designs. Applications include industrial control systems, communication devices, instrumentation, and electronic clock synthesizers.

High-speed CMOS logic benefits from low power and compatibility. Wide voltage range operation ensures design flexibility. Robust operating temperature supports industrial and automotive contexts. PDIP package simplifies installation and prototyping.

Single output PLL design for frequency synthesis and signal conditioning. TTL compatible inputs enable broad circuit integration. Compact footprint for efficient PCB layout. Used in timing, frequency generation, and synchronization applications.
