Broadcom Miniature Isolation Amplifier 8-Pin SSOP 5 - 5.5V ACPL-C784-000E

Broadcom ACPL-C784-000E miniature isolation amplifier is a high-performance optocoupler designed for industrial environments requiring electrical signal isolation. Operating at a supply voltage range of 5 to 5.5 volts, this device provides a single isolation channel packaged in a compact 8-pin SSOP form factor.

Its miniature isolation design facilitates the insulation of high voltage signals, ensuring the safe separation of control and power circuits to protect sensitive components. Featuring sigma-delta modulator technology, it enables precise measurement of phase current and bus voltage, critical in motor drives and power inverter applications.

The device exhibits a high common mode rejection ratio of 76 dB, minimizing noise interference for accurate signal processing. It withstands isolation voltages up to 5000 Vrms, meeting rigorous industrial safety standards such as IEC/EN/DIN EN 60747-5-5, UL 1577, and CSA certifications. The operating temperature range from -40°C to 85°C allows robust performance across diverse environmental conditions.

Compact and lightweight, the ACPL-C784-000E amplifier measures just 5.85 mm in length and 3.18 mm in height, promoting efficient PCB layout and integration. It serves as an effective alternative to Hall Effect amplifiers for current and voltage sensing in power converters and other isolation circuits requiring short-circuit and overload detection capabilities.

Electrical isolation up to 5000 Vrms enhances system safety and noise immunity. Single channel, 8-pin SSOP package balances size and functionality. Wide operating temperature range (-40°C to 85°C) ensures reliability. High CMRR of 76 dB reduces common-mode noise impacts.

Sigma-delta modulator technology for precise sensor signal conversion. Conforms to IEC/EN/DIN EN 60747-5-5, UL 1577, CSA for industry compliance. Compact dimensions support efficient PCB space utilization. Ideal for industrial, manufacturing, and power conversion applications requiring precise isolation amplification.

For professional industrial and manufacturing applications, the Broadcom ACPL-C784-000E miniature Isolation Amplifier ensures effective electrical isolation, precision sensing, and compliance with global safety standards. Explore EnvMart's comprehensive electronics catalog for more semiconductor amplifiers and components suited to your engineering needs.
