Broadcom Isolation Amplifier, 8-Pin PDIP, 5.5V Supply Voltage ACPL-7900-300E

Broadcom ACPL-7900-300E Isolation Amplifier is a precision single-channel device in an 8-pin PDIP package supporting a maximum supply voltage of 5.5V. It is ideal for applications in industrial electronics where effective isolation and signal integrity are critical.

The device employs sigma-delta modulator technology to facilitate accurate measurements and isolation, commonly used in motor drives, power inverters, and general voltage isolation circuits. This technology enables the isolation amplifier to deliver high common mode rejection, minimizing interference and ensuring safety insulation.

The 8-pin PDIP package supports surface mount assembly with a length of 9.8 mm and height of 3.56 mm, making it suitable for compact printed circuit boards. It can operate reliably over a wide temperature range of -40°C to 105°C, which meets industrial environmental requirements.

The input offset voltage is a low 2 mV, and the common mode rejection ratio is rated at 76 dB, delivering excellent noise immunity and accurate signal isolation performance. While this model does not have specific automotive certifications, its robust construction suits various industrial isolation amplifier needs.

Applications include current and voltage sensing in power converters, isolation in signal conditioning circuits, and usage as an isolated linear sensing integrated circuit. The part is supplied in a tube and designed for easy insertion into machinery and electronic assemblies, enhancing production efficiency.

Operates with supply voltages from 3V to 5.5V ensuring versatile power options. Provides a single channel for precise isolation amplification. 8-pin PDIP package allows for reliable through-hole mounting. Offers an input offset voltage of 2 mV for accurate signal processing.

Common Mode Rejection Ratio of 76 dB ensures effective noise immunity. Wide operating temperature range from -40°C to 105°C for industrial reliability. Compact dimensions of 9.8mm length and 3.56mm height enable space-efficient PCB design.

This Broadcom isolation amplifier is suitable for industrial, electronics manufacturing, and general electronic component applications. Discover more electronic components and Isolation Amplifiers on EnvMart.
