Texas Instruments Data Acquisition IC 16 bit 0.5 Msps 38-Pin TSSOP ADS8688IDBT

Free Delivery in India | Lowest Global Shipping Charges

Texas Instruments Data Acquisition IC 16 bit 0.5 Msps 38-Pin TSSOP ADS8688IDBT

Name: Texas Instruments Data Acquisition IC 16 bit 0.5 Msps 38-Pin TSSOP ADS8688IDBT
Brand: Texas Instruments
SKU: 382850
Price: 31.45 USD
Availability: InStock



Category Data Acquisition IC Brand Texas Instruments Condition New

Specifications

Country of Origin	India
Resolution	16 bit
Brand	Texas Instruments
Height	1.05mm
Length	9.8mm
Model	ADS8688IDBT
Mount Type	Surface
Sampling rate	500ksps
Series	ADS868x
Maximum Operating Temperature	125°C
Package Type	TSSOP
Sub Type	ADC & DAC
Minimum Operating Temperature	-40°C
Pin Count	38
Maximum Supply Voltage	5.25V
Minimum Supply Voltage	3.3V
Number of ADCs	1
Low Power Consumption	65 mW

Key Features

This device includes one 16-bit SAR ADC to provide high resolution digital outputs.
Supports programmable input ranges with bipolar and unipolar options.
Over-voltage protection up to ±20 V ensures device safety.
Features a SPI compatible serial digital interface with daisy-chain capability.
Low power consumption design at 65 mW for efficient operation.
Operates within a temperature range from -40°C to 125°C.
Surface mount device with a compact height of 1.05 mm and length of 9.8 mm.
Supported supply voltage from 3.3 V to 5.25 V.

Product Description

Texas Instruments ADS8688IDBT is a high-performance 16-bit data acquisition IC designed for precise analog-to-digital conversion needs. It offers a sampling rate of 0.5 Msps and comes housed in a 38-Pin Thin Shrink Small Outline Package (TSSOP) suitable for surface mount applications. The device integrates a single 16-bit SAR ADC with a constant resistive input impedance of 1 MΩ and analog input overvoltage protection up to ±20 V, ensuring reliable performance in demanding electronics conditions.

This IC provides programmable input voltage ranges, supporting bipolar inputs of ±2.56, ±5.12, and ±10.24 volts, as well as unipolar ranges of 5.12 and 10.24 volts. It operates at low power consumption, approximately 65 milliwatts, making it energy-efficient for widespread industrial use. The digital interface is SPI compatible with daisy chaining capabilities, facilitating expanded system integration.

Engineered to operate between temperatures ranging from -40°C to 125°C, the ADS8688IDBT suits industrial, laboratory, and electronic manufacturing environments that require robust and accurate data conversion. With supply voltage ranging from 3.3 V to a maximum of 5.25 V, it provides design flexibility for various electronic systems.

Incorporates a 16-bit SAR ADC for precise data acquisition. Programmable bipolar and unipolar input voltage ranges enhance versatility. High input impedance of 1 MΩ ensures stable analog signal processing. Robust overvoltage protection extends circuit durability.

SPI compatible interface supports simplified communication and daisy chaining of devices. Energy efficient with 65 mW power consumption. Compact 38-pin TSSOP surface mount package with a height of 1.05 mm and length of 9.8 mm.

Wide operational temperature range of -40°C to 125°C suitable for harsh environments. Supports 3.3 V to 5.25 V supply for design flexibility.

This Texas Instruments ADS8688IDBT data acquisition IC is highly suitable for use in industrial machines and instruments, measuring and testing instrumentation, and general data conversion applications. For additional product selections and detailed technical information, browse EnvMart's Electronics & Electricals semiconductor and Data Acquisition IC categories.
