Wurth Elektronik 3524 Series Pluggable Terminal Block 2-Contact 7.62 mm Pitch 1 Row 300V AC 15A 691352410002

Wurth Elektronik 691352410002 series pluggable terminal block is designed for both industrial and electronic component integration requiring secure and reliable wire connections. This terminal block provides 2 contacts arranged in a single row with a pitch of 7.62 mm, delivering efficient electrical contact and easy PCB mounting.

It supports a continuous current of up to 15A and accommodates wire sizes from AWG 24 to AWG 12, making it adaptable to various wiring needs in power distribution and control systems.

The housing is manufactured from polyamide (PA66), known for its robustness and UL94-V0 flame retardancy, making it suitable for demanding electrical environments. The green color assists in easy identification and assembly on the PCB.

Wurth’s WR-TBL 3524 series incorporates a straight orientation with cable entry wire connection method that enhances installation convenience. The terminal block includes a retention latch on the wire side and a slot type M3 screw terminal to ensure solid and vibration-resistant cable fixation.

Operating at a voltage of 300V AC, this terminal block is ideal for use in industrial automation, control panels, electronic devices, and power supply applications. The tin-plated phosphor bronze wire guard improves conductivity and corrosion resistance, prolonging component life.

The compact dimensions of 13.22 mm length, 12.6 mm width, and 26 mm depth enable efficient space utilization in crowded PCB layouts or modular assemblies. The terminal block supports a current rating of 15A for reliable power handling.

Wire size compatibility ranges from 24 AWG to 12 AWG for versatile applications. Constructed with green polyamide housing providing durability and UL94-V0 flame retardant properties. The connector features a straight orientation and uses a cable entry wire connection method.

This component operates at a voltage rating of 300V AC, suitable for industrial and electronic use. Compact footprint with length 13.22mm, width 12.6mm, and depth 26mm for space saving PCB design. Made in China with tin-plated phosphor bronze wire guard ensuring corrosion resistance.

Designed with a retention latch and slot type M3 screw terminals for secure wire connections.

This pluggable terminal block from Wurth Elektronik is an essential component in power connectors, offering reliable electrical connections for manufacturing, industrial automation, electronics prototyping, and maintenance. Browse more in Pluggable Terminal Blocks and connectors at EnvMart for quality assured electronic components.
