Panasonic PCB Power Relay 12V DC Coil 10A Switching Current SPST DK1A-L2-12V-F
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 10mm |
| Length | 20mm |
| Model | DK1A-L2-12V-F |
| Width | 12.5mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | DK1A |
| Maximum Operating Temperature | 65°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| High Sensitivity | 200 mW nominal operating power |
| Contact Resistance | 30mΩ |
| Standards/Approvals | UL, CSA, VDE |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 125V dc |
| Switching AC Voltage | 125V ac |
| Coil Power | 200mW |
Key Features
- The relay operates with a coil voltage of 12V DC and a switching current of 10A.
- Contact configuration is Single Pole Single Throw (SPST) suitable for various switching applications.
- Compact dimensions with height 10mm, width 12.5mm, and length 20mm enable easy PCB integration.
- Constructed with silver alloy contacts and offers high sensitivity with 200 mW nominal operating power.
- Designed to operate in temperatures ranging from -40°C to 65°C for reliable performance.
- Switching voltage ratings are 125V AC and 125V DC, suitable for power switching use cases.
- The sealed construction allows automatic washing and high breakdown voltage, ensuring durability.
- UL, CSA, and VDE approvals provide compliance with international safety standards.
Product Description
Panasonic DK1A-L2-12V-F PCB Power Relay is a miniature high-capacity relay featuring a 12V DC coil and 10A switching current capacity, designed for reliable power switching in industrial and commercial electrical applications. With its Single Pole Single Throw (SPST) contact configuration and compact PCB mounting form factor, this relay suits various automation and control systems.
The relay's low nominal operating power of 200 mW combined with silver alloy contacts ensures high sensitivity and efficient performance. Its sealed construction offers protection and allows automatic washing, enhancing longevity and reliability even under demanding conditions.
Dimensions of 10mm height, 12.5mm width, and 20mm length make it suitable for space-constrained PCB layouts. Operating temperature range from -40°C to 65°C allows functioning in harsh industrial environments.
The relay is UL, CSA, and VDE approved, confirming compliance with major safety standards. Its switching voltage rating supports up to 125V AC and 125V DC, enabling wide application in power switching roles.
Typical use cases include power switching for industrial machinery, programmable logic controllers (PLCs), temperature controllers, timers, and household appliances. Its design ensures durability, high surge withstanding capability, and suitability for automation tasks.
The relay operates with a coil voltage of 12V DC and a switching current of 10A. Contact configuration is SPST for straightforward single-circuit switching operations. Compact dimensions facilitate easy integration into printed circuit boards.
High sensitivity achieved with 200 mW nominal operating power and silver alloy contacts. Wide operating temperature range supports use in varied environmental conditions. Switching voltage capacity up to 125V AC/DC makes it versatile for many applications.
Sealed construction enhances durability and immunity from environmental contaminants. Approved to UL, CSA, and VDE standards for international safety assurance. Ideal for demanding industrial automation, manufacturing, HVAC, and electrical applications.
Explore EnvMart's selection of Power Relays for high-quality industrial electrical components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current capacity of 10A, making it suitable for various power switching applications.
This model operates with a coil voltage of 12V DC.
The relay has a height of 10mm, a width of 12.5mm, and a length of 20mm, allowing for easy integration into PCB layouts.
The relay features a Single Pole Single Throw (SPST) contact configuration, suitable for straightforward switching operations.
It operates within a temperature range of -40°C to 65°C, making it suitable for harsh environments.
The relay has a nominal operating power of 200 mW, which contributes to its high sensitivity.
This relay supports switching voltage ratings of up to 125V AC and 125V DC.
The contacts are made of silver alloy, which enhances performance and reliability.
Yes, it is approved to UL, CSA, and VDE standards, ensuring compliance with international safety regulations.
This model is designed for PCB mounting, making it suitable for various electronic applications.
The contact resistance is 30mΩ, which contributes to its efficient performance in switching applications.
It features PCB pin terminals, facilitating easy connection to printed circuit boards.
