onsemi 3 State Bus Buffer 20-Pin SOIC MC74LVX541DWG

Free Delivery in India | Lowest Global Shipping Charges

onsemi 3 State Bus Buffer 20-Pin SOIC MC74LVX541DWG

Name: onsemi 3 State Bus Buffer 20-Pin SOIC MC74LVX541DWG
Brand: onsemi
SKU: 374402
Price: 0.93 USD
Availability: InStock



Category Buffers Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	2.4mm
Operating Voltage Range	2.7 to 5.5V
Length	12.95mm
Model	MC74LVX541DWG
Mount Type	Surface
Output type	3 State
Series	MC74LVX541
Input Type	CMOS
Maximum Operating Temperature	85°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Pin Count	20
Maximum Supply Voltage	3.6V
Logic Family	LVX
Logic Function	Buffer
Minimum Supply Voltage	2V
Maximum High Level Output Current	-4mA
Maximum Propagation Delay Time @ CL	12ns
Supply Current	50mA
Maximum Low Level Output Current	4mA

Key Features

Operates with a supply voltage range from 2.7V to 5.5V.
Features 20 pins in a compact SOIC surface mount package.
Maximum propagation delay time of 12 nanoseconds allows high-speed signal processing.
CMOS input type with 3 state outputs provides high flexibility in bus control.
Designed for operation from -40°C to 85°C ambient temperature.
Maximum high-level output current of -4mA and low-level output current of 4mA ensures efficient switching.
Low supply current of 50mA supports energy-efficient designs.
Compact dimensions of 12.95mm length and 2.4mm height enable space-saving PCB layouts.

Product Description

onsemi MC74LVX541DWG is a 3 state bus buffer integrated circuit designed for high-speed and low-voltage CMOS logic applications. Packaged in a 20-pin SOIC surface mount type, it operates effectively within a supply voltage range of 2.7 to 5.5 volts, making it suitable for a broad range of electronic systems.

This IC provides CMOS input type with three-state output capability, ideal for buffering and bus interfacing in electronic circuits. It does not include a Schmitt trigger input feature, focusing instead on buffering performance.

The device features a maximum propagation delay time of 12 nanoseconds at specified load conditions, enabling fast switching speeds required in digital signal processing. It supports a maximum high-level output current of -4mA and low-level output current of 4mA, facilitating reliable drive capacity in bus applications.

Designed for industrial operational reliability, the MC74LVX541DWG functions within a temperature range of -40°C to 85°C. Its low supply current of 50mA minimizes power consumption, beneficial in energy-sensitive projects.

The physical dimensions of the IC are 12.95mm in length and 2.4mm in height, accommodating compact PCB footprint requirements. It is part of the 74LVX family known for advanced CMOS logic solutions.

Operates within a voltage range of 2.7V to 5.5V. Features 20-pin SOIC surface mount package. Maximum propagation delay time of 12ns ensures high-speed operation. CMOS input type with 3 state output enhances bus control flexibility.

Operational temperature range from -40°C to 85°C. Maximum output currents: -4mA (high), 4mA (low) for efficient switching. Low supply current of 50mA supports energy efficiency. Compact size with 12.95mm length and 2.4mm height.

This bus buffer IC is widely used in industrial electronics, semiconductor device applications, digital logic circuit designs, and manufacturing processes requiring reliable signal buffering and bus integrity. It is suitable for use in electronic components assemblies within semiconductor and electronics industries.

Explore more semiconductor solutions and related products in the Buffers category on EnvMart for comprehensive sourcing needs.
