onsemi 6-Channel Non-Inverting 3 State Buffer, 16-Pin SOIC MC14503BDG

Free Delivery in India | Lowest Global Shipping Charges

onsemi 6-Channel Non-Inverting 3 State Buffer, 16-Pin SOIC MC14503BDG

Name: onsemi 6-Channel Non-Inverting 3 State Buffer, 16-Pin SOIC MC14503BDG
Brand: onsemi
SKU: 374386
Price: 0.6 USD
Availability: InStock



Category Buffers Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.5mm
Length	10mm
Model	MC14503BDG
Mount Type	Surface
Output type	3 State
Series	MC14503B
Input Type	Single Ended
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-55°C
Polarity	Non-Inverting
Number Of Channels	6
Pin Count	16
Automotive Standard	AEC-Q100
Maximum Supply Voltage	18V
Logic Family	CMOS
Logic Function	Buffer
Minimum Supply Voltage	3V
Maximum High Level Output Current	19.2mA
Maximum Propagation Delay Time @ CL	200ns
Supply Current	15μA
Maximum Low Level Output Current	-8.2mA
Wide operating voltage range	3 to 18V

Key Features

CMOS logic family ensuring low power consumption.
Six channels supporting non-inverting buffer function.
3-state output enables bus-oriented applications.
Wide operating voltage range from 3V to 18V.
Surface mount SOIC package with 16 pins for efficient PCB design.
Robust operating temperature from -55°C to 125°C for industrial use.
Low supply current of 15µA enhances energy efficiency.
Maximum propagation delay of 200ns suitable for moderate speed operations.

Product Description

onsemi MC14503BDG is a 6-Channel Non-Inverting 3 State Buffer in a space-saving 16-Pin SOIC surface mount package designed for versatile logic IC applications. Featuring the CMOS logic family, it ensures low supply current consumption of 15μA making it energy efficient for both commercial and industrial electronic circuits.

This buffer device provides six independent channels with non-inverting 3-state outputs, permitting efficient bus isolation and driving. Its wide operating voltage range of 3V to 18V allows compatibility with a variety of circuits and power supplies, supporting flexible design requirements.

The operating temperature range of -55°C to 125°C makes it highly suitable for harsh environmental conditions including automotive and industrial applications. It conforms to AEC-Q100 automotive standards, guaranteeing enhanced reliability for critical use cases.

The device offers a maximum propagation delay of 200ns at standard capacitive loading, ensuring timely signal buffering while maintaining signal integrity. The output current capability includes a maximum high-level output current of 19.2mA and low-level output current of -8.2mA, allowing effective driving of subsequent stages.

Compact 16-Pin SOIC surface mount package enables easy PCB layout. CMOS construction reduces power consumption and heat generation. Wide supply voltage range increases compatibility across different systems. High temperature tolerance supports industrial and automotive environments.

3-state output facilitates bus-oriented applications. Industry standard AEC-Q100 qualification ensures dependable operation. Low operating current enhances overall system efficiency. Onsemi MC14503BDG belongs to the MC14503B series, providing consistent performance.

Ideal for electronic engineers and designers requiring a dependable buffer IC for logic signal conditioning in industrial automation, automotive electronics, and general-purpose industrial controls. Easily integrated into compact electronic designs, this device helps optimize functionality while minimizing power usage.

Explore more semiconductor components and electronic solutions at EnvMart for your professional industrial and laboratory projects.

Explore more products in our Buffers category.
