onsemi Zener Diode 2.4 V 500 mW Surface Mount 2-Pin SOD-523 MM5Z2V4T1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Zener Diode 2.4 V 500 mW Surface Mount 2-Pin SOD-523 MM5Z2V4T1G

Name: onsemi Zener Diode 2.4 V 500 mW Surface Mount 2-Pin SOD-523 MM5Z2V4T1G
Brand: onsemi
SKU: 373541
Price: 0.04 USD
Availability: InStock



Category Zener Diode Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	0.7mm
Length	1.7mm
Model	MM5Z2V4T1G
Mount Type	Surface
Series	MM5ZxxxT1G
Maximum Operating Temperature	150°C
Package Type	SOD-523
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50μA
Nominal Zener Voltage Vz	2.4V
Zener Type	Voltage Regulator
Maximum Zener Impedance	100Ω
Typical Voltage Temperature Coefficient	0mV/K
Surface Mount case	SOD-523

Key Features

The diode features a single element per chip configuration.
It is packaged in a compact SOD-523 surface mount case optimized for efficient board space usage.
Maximum power dissipation rating is 500 milliwatts.
Nominal Zener voltage is 2.4 volts with a test current of 5 milliamps.
The device supports a broad operating temperature range from -65°C to 150°C.
Pin count is 2 with a height of 0.7 mm and length of 1.7 mm for low-profile installation.
Maximum Zener impedance is 100 ohms with a maximum reverse leakage current of 50 microamperes.
RoHS compliant, ideal for environmentally conscious manufacturing.

Product Description

onsemi MM5Z2V4T1G is a high-quality 2.4 V Zener diode designed for reliable voltage regulation in electronic circuits. This device features a single diode element in a surface mount SOD-523 package, optimized for compact board layouts in industrial, commercial, and consumer electronics applications.

With a maximum power dissipation of 500 mW, it ensures robust performance under moderate load conditions. The diode maintains stable operation across a wide temperature range from -65°C to 150°C, making it suitable for demanding environments such as automotive electronics, power supplies, and voltage reference circuits.

Key parameters include a nominal Zener voltage of 2.4 V at a test current of 5 mA, a maximum Zener impedance of 100 ohms, and a low maximum reverse leakage current of 50 microamperes, ensuring efficient voltage regulation with minimal losses.

The compact height of 0.7 mm and length of 1.7 mm enable low-profile surface mounting, facilitating use in space-constrained designs. The diode features a single element per chip for straightforward application. The surface mount SOD-523 package supports automated assembly processes.

RoHS compliance aligns with global environmental standards. Applications include voltage regulation, voltage reference, and protective circuits. Suitable for use in industrial, laboratory, automotive, and telecommunications electronics.

Choose onsemi MM5Z2V4T1G Zener Diode for dependable, industry-standard voltage regulation components in your electronic designs. Browse related semiconductor components at EnvMart for complementary products.
