onsemi 24 V Zener Diode Single 500 mW 5 % Surface Mount 2-Pin SOD-123 MMSZ24T1G

Name: onsemi 24 V Zener Diode Single 500 mW 5 % Surface Mount 2-Pin SOD-123 MMSZ24T1G
Brand: onsemi
SKU: 373448
Price: 0.03 USD
Availability: InStock



Category Zener Diode Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	3.68mm
Model	MMSZ24T1G
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	50nA
Nominal Zener Voltage Vz	24V
Zener Type	Voltage Regulator
Maximum Zener Impedance	70Ω
Surface Mount case	SOD-123

Key Features

Designed for voltage regulation and protection in electronic circuits.
Comes in a compact SOD-123 surface mount package for efficient PCB integration.
Maximum power dissipation of 500 mW ensures reliable operation under load.
Features a 5 % Zener voltage tolerance for accurate voltage regulation.
Single diode element with 2 pins for easy mounting and connectivity.
Test current of 5 mA to characterize device performance.
Operating temperature range from -55°C to 150°C for robust industrial use.
Low reverse leakage current of 50 nA minimizes power loss in protective applications.

Product Description

onsemi MMSZ24T1G is a surface mount Zener diode designed as a voltage regulator with a nominal Zener voltage of 24 V and a maximum power dissipation of 500 mW. It is configured as a single-element diode and housed in a compact SOD-123 package, compatible with automated PCB assembly processes.

This diode features a precise voltage tolerance of ±5 %, providing stable voltage regulation necessary in power supply and protection circuits. It operates reliably over a wide temperature range from -55°C to 150°C, suitable for demanding industrial and automotive environments.

The device has a test current rating of 5 mA and a maximum Zener impedance of 70 Ohms, ensuring low noise and consistent performance. Its low maximum reverse leakage current of 50 nA also contributes to energy-efficient designs. The diode's 2-pin configuration enables easy integration into various circuit boards.

Applications of the MMSZ24T1G include voltage regulation, voltage reference in measurement and control systems, and protection of sensitive components from voltage spikes. It is widely used in electronic manufacturing, automotive electronics, telecommunications devices, and general industrial machinery where compact, high-reliability components are essential.

Designed for voltage regulation and protection in electronic circuits. Compact SOD-123 surface mount package for efficient PCB integration. Robust power handling with 500 mW maximum dissipation. Precise 5 % Zener voltage tolerance for stable operation.

Wide temperature range suitable for automotive and industrial use. Low reverse leakage current to minimize energy loss. Reliable single diode element with 2 pin connections. Facilitates automated manufacturing for high volume production.

Widely applicable in telecommunications, instrumentation, and control systems.

For electronics manufacturers and engineers seeking reliable voltage regulation components, the onsemi MMSZ24T1G provides a durable, efficient solution. Browse our comprehensive selection of discrete semiconductors in the Zener Diode category for compatible parts and accessories.
