| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.3mm |
| Length | 3.05mm |
| Model | SN74LVC1G126DBVR |
| Mount Type | Surface |
| Compatibility | Input LVTTL/TTL, Output LVCMOS |
| Output type | 3 State |
| Series | SN74LVC1G126 |
| Input Type | TTL, CMOS |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Polarity | Non-Inverting |
| Number Of Channels | 1 |
| Operating Voltage | 1.65 to 3.6V |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | 74LVC |
| Logic Function | Buffer |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | -32mA |
| Maximum Low Level Output Current | 32mA |
Texas Instruments SN74LVC1G126DBVR is a high-performance non-inverting 3 state buffer logic IC designed for low-voltage CMOS logic family 74LVC. This device operates on supply voltages ranging from 1.65V up to 5.5V and features 5V tolerant inputs, providing compatibility with both LVTTL/TTL inputs and LVCMOS outputs. Packaged in a compact 5-pin SOT-23 form factor, it enables space-saving surface mount applications in modern electronics design.
With one channel, this buffer offers a three-state output that allows for improved bus driving and signal control in digital systems. Its maximum operating ambient temperature of 125°C and minimum of -40°C supports use in robust industrial environments. The buffer supports a maximum low level output current of 32mA and a high level output current of -32mA, making it suitable for driving moderate loads.
The device is RoHS compliant, ensuring environmentally friendly manufacturing standards. Its small package height of 1.3mm and length of 3.05mm is ideal for compact printed circuit boards.
This buffer IC finds applications in industrial automation systems, communication devices, instrumentation, control hardware, and other embedded systems requiring reliable and efficient signal buffering under varying electrical conditions.
Operates at supply voltages from 1.65V to 5.5V with 5V tolerant inputs. Non-inverting buffer with 3 state output in a 5-pin SOT-23 package. Compatible with TTL and CMOS inputs for versatile interfacing. Operating temperature range from -40°C to 125°C for industrial use.
Compact dimensions suitable for small form factor PCBs. RoHS compliant product ensuring adherence to environmental standards. Maximum output drive currents enable robust signal transmission. Designed for surface mount applications to improve assembly efficiency.
