Wurth Elektronik Wirewound Surface Mount Inductor Shielded 150 μH ±20% 1.8 A Idc 1280 WE-PD 744770215

Wurth Elektronik model 744770215 is a wirewound surface mount inductor from the WE-PD series, featuring an inductance of 150 μH ±20% tolerance and a maximum DC current of 1.8 A. This shielded inductor is engineered for demanding electronic applications where low magnetic leakage and high current capacity are critical.

It is housed in a compact 1280 package with dimensions 12 mm (length) x 8 mm (height) x 12 mm (depth), and offers a maximum DC resistance of 280 milliohms, reducing power losses in circuits. The inductor supports operating temperatures ranging from -40 °C up to 125 °C and meets automotive standard AEC-Q200, which ensures suitability for automotive and industrial environments.

This product is designed with a magnetically shielded construction to minimize interference and noise, making it ideal for integration into switching regulators with low operating voltages, as well as integrated DC/DC converters. Its recommended solder profile is reflow, compatible with standard SMT assembly processes. With a maximum self-resonant frequency of 3 MHz, it supports high-frequency electronic designs such as graphic cards and other power electronics aiming for efficiency greater than 86%.

Magnetically shielded wirewound construction for reduced electromagnetic interference. Compact 1280 package case suitable for surface mount technology. High current rating of 1.8 A allowing usage in power-intensive circuits.

Wide temperature range enabling durable automotive and industrial applications. Low DC resistance (280 mΩ) for energy efficient operation. Meets IPC/JEDEC J-STD-020D standards for quality and performance. Suitable for switching regulators and DC/DC converters requiring low losses and high efficiency.

This Wurth Elektronik Surface Mount Inductor is ideal for industrial electronics, automotive applications, power supply modules, and graphics hardware requiring compact, reliable inductors capable of handling significant currents at high frequency ranges. Environmentally qualified and robust, the 744770215 model provides trustworthy performance in professional and industrial use cases.
