onsemi 1.56 V Zener Diode 225 mW Single Surface Mount 3-Pin SOT-23 SZBZX84C5V6ET3G

onsemi SZBZX84C5V6ET3G is a high-quality 1.56 V Zener Diode designed for surface mount applications requiring precise voltage regulation with a single diode configuration. This device is rated at a maximum power dissipation of 225 mW and housed in a compact 3-pin SOT-23 package, making it ideal for efficient PCB integration and space-constrained electronic designs.

The diode operates reliably over a broad temperature range from -65°C to 150°C, ensuring stable performance in industrial, automotive, and consumer electronics systems. It features a nominal Zener voltage of 5.6 V with ±7% tolerance, providing precise voltage reference and regulation capabilities.

The device’s maximum reverse leakage current is only 1 μA, emphasizing low current losses and enhanced efficiency, while a maximum Zener impedance of 40 Ω at a test current of 5 mA guarantees stable voltage behavior. With a typical voltage temperature coefficient of 2.5 mV/°C, the voltage stability remains consistent despite temperature variations.

Measurement dimensions such as a height of 1.11 mm and length of 3.04 mm confirm a compact form factor, optimizing circuit board layout. This Zener diode series (SZBZX84) by onsemi is manufactured to meet rigorous quality standards though without specific certifications mentioned.

This diode is suitable for various industries including electronics manufacturing, industrial controls, telecommunications, automotive electronics, and general purpose voltage regulation in power supplies and protective circuits.

This Zener diode delivers a nominal voltage of 5.6 volts with ±7% tolerance. Maximum power dissipation is rated at 225 mW ensuring reliable operation. Surface mount technology with a compact SOT-23 3-pin package for PCB applications.

Operates within a temperature range of -65°C to 150°C suitable for diverse environments. Maximum reverse leakage current is extremely low at 1 microampere, improving efficiency. Maximum Zener impedance of 40 ohms with a test current of 5 mA for stability.

Height of 1.11 mm and length of 3.04 mm contribute to space-saving circuit design. Typical voltage temperature coefficient of 2.5 mV/°C enhances voltage stability with temperature change. Explore a wide range of high-quality Zener Diodes and semiconductor components at EnvMart for your industrial, laboratory, and electronic device manufacturing needs.
