Hirose DF11 Series Straight Surface PCB Socket 24-Contact 2 Row 2 mm Pitch Solder

Hirose DF11CZ-24DS-2V(52) PCB Socket is a premium 24-contact, 2-row straight surface mount connector with a 2 mm pitch solder termination. It belongs to the DF11 series renowned for compact double row designs combining space efficiency with robust electrical performance. The low profile connector has a housing made from polyamide, ensuring mechanical strength and reliability in industrial applications.

The contacts are made of copper with gold and tin plating to provide excellent conductivity and resistance to corrosion. It supports a continuous current of 12A and a voltage rating up to 30V, making it ideal for low voltage electronic circuits. The connector features guide ribs to prevent mismating and twisting, thus safeguarding against installation errors.

Metal fittings on this SMT version enhance PCB retention and help prevent solder peel, improving long-term durability in board-to-board and cable-to-board setups. The operating temperature range from -30°C to 85°C broadens its suitability for applications requiring reliable performance under challenging environmental conditions.

Typical industrial and commercial applications include portable electronic devices requiring multiple signal paths in a limited footprint, such as digital cameras, LCD display panels, digital video recorders, car navigation systems, access control devices, and various precision measurement instruments.

The compact double row layout supports high-density PCB interconnections while saving board space. Polyamide housing ensures strong mechanical and thermal performance. Copper contacts plated with gold and tin enhance contact reliability and corrosion resistance.

Guide ribs prevent incorrect insertion, protecting device circuitry. Metal fittings reinforce PCB retention and minimize solder joint failures. 12A current rating and 30V voltage rating support a range of low voltage applications.

Wide operating temperature range covers typical industrial environments. Widely used in electronics manufacturing, industrial equipment, and consumer electronics.

This Hirose DF11 Series PCB Socket is supplied on a reel optimized for automated assembly lines to increase production efficiency. It is a vital component in electronics manufacturing, ensuring secure, durable connections in modern compact devices.

Explore more connectors and electronic components within the PCB Socket category at EnvMart to find compatible and complementary products for your industrial and commercial projects.
