Panasonic EXJZ Series SMT Transient Suppressor Varistor 18V DC, 20A, 1.6mm x 0.8mm EZJZ1V800AA
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Length | 1.6mm |
| Model | EZJZ1V800AA |
| Depth | 0.8mm |
| Series | EXJZ |
| Maximum Operating Temperature | 85°C |
| Maximum dc Voltage | 18V dc |
| Standards/Approvals | RoHS |
| Maximum Surge Current | 20A |
Key Features
- This varistor features an 18V DC maximum voltage rating for effective surge protection.
- It can handle a maximum surge current of 20 amperes ensuring robust transient suppression.
- Compact dimensions of 1.6mm length and 0.8mm depth provide space-saving PCB integration.
- Constructed with advanced semiconductive ceramics for excellent electrostatic discharge resistance.
- Lead-free terminal electrodes ensure great solderability, but flow soldering should be avoided.
- Ideal for applications such as HDMI, USB 2.0, and IEEE1394 interface ESD protection.
- Meets RoHS compliance and IEC61000-4-2 Level 4 electrostatic discharge standards.
- Designed as a bipolar multilayer varistor requiring no polarity consideration.
Product Description
Panasonic EZJZ1V800AA is an SMT transient suppressor varistor in the EZJZ series, constructed from advanced semiconductive ceramics ensuring superior electrostatic discharge (ESD) suppression with a multilayer bipolar design that eliminates polarity concerns.
With a maximum DC voltage rating of 18V and a surge current capacity of 20A, this compact varistor (1.6mm length by 0.8mm depth) is perfectly suited for protecting sensitive high-speed data lines.
Its ultra-low capacitance and lead-free terminal electrodes provide excellent solderability without requiring flow soldering, enhancing manufacturing efficiency and reliability.
This product is RoHS compliant and meets IEC61000-4-2 Level 4 standards for electrostatic resistance, ensuring reliable protection in demanding industrial, electronic, and communication equipment environments.
Applications include surge and ESD protection on HDMI high-speed data buses, USB 2.0 ports, and IEEE1394 serial bus interfaces, making it ideal for use in consumer electronics, industrial control systems, and communication devices.
This varistor is bipolar with no polarity, simplifying installation. Its multilayer design supports protection of multiple signal lines. Ensures long-term reliability with high electrostatic resistance. Complies with environmental and safety standards including RoHS.
Manufactured in Japan ensuring high-quality production standards. This Varistor enhances the durability and performance of electronic assemblies by protecting against transient voltages and electrostatic discharges. Explore more surge protection components and Panasonic electronic parts on EnvMart to meet your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum DC voltage rating of this varistor is 18V.
It can handle a maximum surge current of 20A.
The dimensions of this model are 1.6mm in length and 0.8mm in depth.
It is constructed with advanced semiconductive ceramics for effective ESD suppression.
No, this varistor is designed as a bipolar component, eliminating the need for polarity consideration.
It meets RoHS compliance and IEC61000-4-2 Level 4 standards for electrostatic discharge.
The maximum operating temperature is 85°C.
It is suitable for applications such as HDMI, USB 2.0, and IEEE1394 interface ESD protection.
Flow soldering should be avoided to ensure optimal solderability.
This varistor is manufactured in Japan.
The ultra-low capacitance enhances its performance in protecting sensitive high-speed data lines.
It features lead-free terminal electrodes that provide excellent solderability.
