onsemi 4 2-Input OR Logic Gate, 14-Pin SOIC, TTL Input, ACT Logic Family, 74ACT32SCX

onsemi 74ACT32SCX is a 4 2-Input OR Logic Gate integrated circuit provided in a 14-pin SOIC surface mount package. Employing Fairchild Semiconductor Advanced CMOS (ACT) logic technology, this device features TTL compatible inputs and CMOS outputs, making it highly versatile for digital logic applications.

Each IC contains four independent OR gates, each with two inputs, providing essential Boolean OR logic functions. The device operates over a voltage range of 2 V to 6 V, with a typical operating voltage between 4.5 V and 5.5 V, suitable for most standard digital circuits.

The maximum propagation delay at a capacitive load is 8.5 nanoseconds, enabling high-speed switching performance. The temperature range accommodates industrial and commercial applications, operating from -40°C to 85°C.

The compact SOIC package ensures efficient PCB space usage, with a height of 1.5 mm and length of 8.75 mm. This component does not feature Schmitt trigger inputs or automotive standard certification.

Suitable for numerous electronic, industrial automation, and embedded system designs, the 74ACT32SCX enables reliable logic integration in manufacturing, test equipment, and consumer electronics.

Contains 4 independent 2-input OR gates providing fundamental logic functions. Advanced CMOS logic enables low power consumption and fast switching. TTL input compatible with CMOS output ensuring wide system compatibility.

Wide operating voltage and temperature range for versatile application environments. Compact SOIC 14-pin surface mount package for efficient PCB layout. Maximum propagation delay of 8.5 ns for rapid signal processing. Not equipped with Schmitt trigger inputs or automotive certifications.

Explore a vast range of semiconductor logic ICs and components at EnvMart for your electronic design needs.
