onsemi 600 V 1 A Fast Recovery Diode 2-Pin Through Hole DO-41 UF4005
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 2.72mm |
| Brand | onsemi |
| Length | 5.2mm |
| Model | UF4005 |
| Mount Type | Through Hole |
| Series | UF4005 |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-41 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 600V |
| Diode Configuration | Single |
| Rectifier Type | Fast Recovery |
| Peak Reverse Current Ir | 50μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 1.7V |
| Peak Reverse Recovery Time trr | 75ns |
Key Features
- This diode features a low forward voltage drop for improved power efficiency.
- It supports a maximum continuous forward current of 1 ampere.
- The peak repetitive reverse voltage rating is 600 volts for high voltage applications.
- Constructed with a glass-passivated junction for enhanced reliability and reduced leakage.
- Capable of handling high surge currents up to 30 amperes peak.
- Fast recovery time of 75 nanoseconds enables efficient switching in circuits.
- Operates reliably across a wide temperature range from -65°C to 150°C.
- The compact DO-41 plastic package measures 5.2 mm in length and 2.72 mm in diameter.
Product Description
The onsemi UF4005 is a fast recovery diode rated at 600 V and 1 A, housed in a 2-pin through-hole DO-41 plastic package. It is designed for efficient power rectification and switching applications requiring fast recovery times and high reliability.
This diode uses a glass-passivated junction which improves reverse voltage resistance and minimizes leakage current, making it suitable for demanding industrial and electronic applications such as power supplies, general-purpose rectification, and high-frequency switching circuits.
Key technical specifications include a maximum continuous forward current of 1 A, a peak repetitive reverse voltage of 600 V, and a high surge current capability up to 30 A, supporting transient conditions without damage. The forward voltage drop is low at 1.7 V, improving power efficiency.
Thermally, the UF4005 operates within a wide temperature range from -65°C to 150°C, accommodating various operational environments including industrial and commercial settings. The compact DO-41 package with a length of 5.2 mm and diameter of 2.72 mm enables easy through-hole mounting for PCB designs.
Low forward voltage drop enhances efficiency. High surge current capability supports transient loads. Glass-passivated junction improves reliability and reduces leakage. Fast recovery time of 75 ns enables high-speed switching.
Wide operating temperature range from -65°C to +150°C. Compact DO-41 through-hole package for easy PCB mounting. Ideal for power supply, industrial, and electronic rectification use cases.
This diode is an essential component in semiconductor diode applications where fast recovery and high voltage ratings are needed. Suitable for use in industrial electronics, power rectification, and manufacturing equipment requiring reliable Diode performance.
Explore related semiconductor components and electronic parts within EnvMart's comprehensive catalog to find compatible components for your application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the UF4005 is 1 ampere.
It has a peak repetitive reverse voltage rating of 600 volts, suitable for high voltage applications.
The forward voltage drop is low at 1.7 volts, which improves power efficiency.
This diode can handle a peak non-repetitive forward surge current of up to 30 amperes.
The UF4005 features a fast recovery time of 75 nanoseconds, enabling efficient switching in circuits.
It operates reliably across a wide temperature range from -65°C to 150°C.
The diode is housed in a DO-41 plastic package, measuring 5.2 mm in length and 2.72 mm in diameter.
It supports through-hole mounting, making it suitable for PCB designs.
The peak reverse current is rated at 50 microamperes.
It is suitable for power supplies, general-purpose rectification, and high-frequency switching circuits.
The UF4005 has a single diode configuration.
It features a glass-passivated junction, which improves reverse voltage resistance and minimizes leakage current.
