Lumberg Minimodul Series Straight Through Hole PCB Header, 8 Contacts, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF 08
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 160V |
| Brand | Lumberg |
| Orientation | Straight |
| Current | 5A |
| Model | 2,5 MSF 08 |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyamide |
| Contact Material | Brass |
| Series | Minimodul |
| Termination Type | Solder |
| Maximum Operating Temperature | 120°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 737-8647Brand: LumbergManufacturers Part No.: 2,5 MSF 08 |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features straight orientation with through hole mounting for reliable board connection.
- Constructed with brass contact material plated with tin for optimal conductivity and corrosion resistance.
- Supports wire-to-board connector system with solder termination type.
- Rated for 5A current and 160V voltage operation within a temperature range of -40°C to 120°C.
- Complies with DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards for safety and performance.
- Ideal for cable-to-board applications in electronics, industrial, and power connectors fields.
- Glass filled polyamide housing enhances durability and electrical insulation.
- Designed for low to medium volume production with easy harnessing of single leads and flat cables.
Product Description
Lumberg 2,5 MSF 08 Minimodul Series Straight Through Hole PCB Header is a precision-engineered 8-contact, 1-row PCB connector featuring a 2.5 mm pitch and shrouded design that ensures secure and durable wire-to-board connections.
Manufactured with high-grade brass contacts plated in tin, this connector supports solder termination and provides excellent electrical conductivity and corrosion resistance.
It operates reliably within a temperature range of -40°C to 120°C and supports currents up to 5A at 160V, complying with industry standards DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11.
The glass-filled polyamide housing offers superior mechanical strength and insulation properties. Its straight orientation and through hole mount type allow for stable insertion and operation on PCBs.
Designed for use in electronics manufacturing, industrial automation, and power connectors applications, this header facilitates easy harnessing of single leads or flat cables using established crimp technology. It is especially suited for low to medium volume productions without compromising reliability.
The shrouded feature ensures contact protection and reduces risks of accidental shorts or damage, enhancing overall system safety and durability. Straight orientation with through hole mounting. 8 male contacts with tin-plated brass material.
Solder termination type for secure connections. 5A current rating and 160V voltage rating. Wide operating temperature range: -40°C to 120°C. Glass filled polyamide housing for durability. Compliant with key international safety standards.
Ideal for electronics, industrial, and power connector applications.
This Lumberg Minimodul PCB Header is an essential component for designers and engineers requiring reliable signal and power interfacing in various industrial and electronic systems. Explore more PCB header solutions at EnvMart for your specific project needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a maximum current of 5A and a voltage of 160V.
The pitch size of this PCB header is 2.5 mm.
It features a through hole mounting type for secure installation on printed circuit boards (PCBs).
The contacts are made of brass and are plated with tin, while the housing is constructed from glass-filled polyamide.
It operates reliably within a temperature range of -40°C to 120°C.
This model features 8 male contacts.
Yes, it complies with DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards.
It supports solder termination for secure connections.
The design orientation of this model is straight, allowing for stable insertion.
It is ideal for cable-to-board applications in electronics, industrial, and power connector fields.
The contacts in this PCB header are male.
The shrouded design ensures contact protection, reducing the risk of accidental shorts or damage.
