Lumberg Minimodul Series Straight Through Hole PCB Header, 2 Contact, 2.5 mm Pitch, 1 Row, Shrouded 2,5 MSF/O 02
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 160V |
| Brand | Lumberg |
| Orientation | Straight |
| Current | 5A |
| Model | 2,5 MSF/O 02 |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyamide |
| Contact Material | Brass |
| Series | Minimodul |
| Termination Type | Solder |
| Maximum Operating Temperature | 120°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 737-8565PBrand: LumbergManufacturers Part No.: 2,5 MSF/O 02 |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Shrouded straight through hole design ensures secure mounting and connection.
- Constructed with glass filled polyamide housing for durability and insulation.
- Can handle currents up to 5A with brass contacts plated with tin for corrosion resistance.
- Supports solder termination and operates from -40°C to 120°C for wide temperature ranges.
- Meets DIN EN 60664/IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards ensuring safety and reliability.
- Provides 1 row with 2 male contacts at 2.5 mm pitch suitable for cable-to-board applications.
- Rated for 160V operating voltage for various industrial and electronic equipment.
Product Description
The Lumberg Minimodul Series Straight Through Hole PCB Header, model 2,5 MSF/O 02, is designed for reliable wire-to-board connections featuring a shrouded, straight orientation with 2 male contacts and a 2.5 mm pitch.
Its glass filled polyamide housing offers enhanced insulation and mechanical strength, while the brass contacts plated with tin ensure excellent conductivity and corrosion resistance. The header supports solder termination and is rated for continuous operation in temperatures ranging from -40°C to 120°C, making it suitable for rigorous industrial and electronic environments.
With a current rating of 5A and voltage rating of 160V, this PCB header meets multiple standards including DIN EN 60664, IEC 60664, IEC 60335-1, and IEC 60695-2-11, underscoring its compliance to safety and performance requirements.
Specially built for cable-to-board applications, the Minimodul series facilitates easy connection with crimp contact housings, making it ideal for signal and low current electrical circuits in industrial, manufacturing, electronic device assembly, and telecommunications equipment.
Shrouded straight through hole design ensures secure and reliable connections. Durable glass filled polyamide housing provides insulation and mechanical stability. Brass male contacts plated with tin guarantee excellent electrical performance and corrosion resistance.
5A current capacity supports low to medium power applications. Operates efficiently across wide temperature range from -40°C to 120°C. Compliant with relevant IEC and DIN safety and performance standards. Ideal for industrial electronics, HVAC controls, telecommunications, and manufacturing automation.
For engineers and technicians requiring a reliable, standardized PCB header, this Lumberg Minimodul part offers consistent performance and ease of integration. Discover more connectors and components suitable for your industrial needs on EnvMart.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current rating of 5A, making it suitable for low to medium power applications.
The voltage rating is 160V, allowing it to be used in various industrial and electronic applications.
It operates efficiently within a temperature range from -40°C to 120°C.
This model supports solder termination, facilitating secure connections.
The housing is made of glass filled polyamide, and the contacts are brass plated with tin for corrosion resistance.
It features 2 male contacts arranged in a single row with a 2.5 mm pitch.
It meets DIN EN 60664, IEC 60664, IEC 60335-1, and IEC 60695-2-11 standards, ensuring safety and reliability.
The header has a straight orientation, designed for through-hole mounting.
This model is shrouded, which helps ensure secure mounting and connection.
It is ideal for wire-to-board connections in industrial electronics, HVAC controls, telecommunications, and manufacturing automation.
The pitch size is 2.5 mm, which is standard for many PCB applications.
The country of origin for this product is India.
