TE Connectivity Dynamic 3000 Series Straight Through Hole PCB Header, 20 Contact(s), 5.08 mm Pitch, 2 Row, Shrouded 316517-5
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 15A |
| Model | 316517-5 |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Copper Alloy |
| Series | Dynamic 3000 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 5.08mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 719-5584Brand: TE ConnectivityManufacturers Part No.: 316517-5 |
| Contact Plating | Tin |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a straight orientation with shrouded design for secure mating.
- Constructed with glass filled polyester housing for durability.
- Contact material made of copper alloy with tin plating for corrosion resistance.
- Supports a current rating of 15A and voltage rating of 600V.
- Operates reliably between -55°C and 105°C temperature range.
- Designed for through-hole mounting with solder termination type.
- Contact gender is male with two rows and a 5.08 mm row pitch.
- Ideal for circuit board connections in electronics and power distribution systems.
Product Description
TE Connectivity model 316517-5 is a Dynamic 3000 Series straight through hole PCB header equipped with 20 contacts arranged in 2 rows at a 5.08 mm pitch. This shrouded header provides a robust wire-to-board connection ideal for electronics and power connector applications requiring reliable performance.
The housing is made from glass filled polyester, enhancing mechanical strength and thermal stability. The contact terminals are crafted from copper alloy with tin plating on contact tails and gold-plated contact tabs to ensure excellent conductivity and resistance to oxidation.
This PCB header supports a continuous current of 15A and withstands voltages up to 600V. It operates efficiently in harsh environments owing to its wide temperature range from -55°C to 105°C. Its through-hole mount style with solder termination guarantees secure installation on compatible PCBs with thicknesses between 1.0 to 1.6 mm.
The shrouded design enhances connection security by protecting the contacts and reducing the risk of damage or misalignment during mating. This makes it especially suitable for industrial, electronics manufacturing, power supply, and various commercial applications where reliable wire-to-board interconnections are critical.
Product compatibility extends to mating D-3500 Series housings, offering system flexibility. Stock number 719-5584 corresponds to this specific header model. Features a straight orientation with shrouded design for secure mating.
Constructed with glass filled polyester housing for durability. Contact material made of copper alloy with tin plating for corrosion resistance. Supports a current rating of 15A and voltage rating of 600V. Operates reliably between -55°C and 105°C temperature range.
Designed for through-hole mounting with solder termination type. Contact gender is male with two rows and a 5.08 mm row pitch. Ideal for circuit board connections in electronics and power distribution systems. Explore TE Connectivity PCB Headers and other Power Connectors categories on EnvMart for comprehensive electronic component solutions.
