TE Connectivity Dynamic 3000 Series Straight Through Hole PCB Header, 4 Contacts, 3.81 mm Pitch, 1 Row, Shrouded 1-178314-5
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 15A |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Copper Alloy |
| Series | Dynamic 3000 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 718-9905PBrand: TE ConnectivityManufacturers Part No.: 1-178314-5 |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a single row with a shrouded design for secure connections.
- Constructed with glass filled polyester housing for durability.
- Rated for 15 amps current at 250 volts.
- Contacts are made of copper alloy with tin plating for reliable conductivity.
- Mount type is through hole, suitable for wire-to-board connections.
- Operates in temperatures ranging from -55°C to 105°C.
- Termination method is solder with male contact gender.
Product Description
TE Connectivity 1-178314-5 Dynamic 3000 Series Straight Through Hole PCB Header is engineered for reliable electronic connections with 4 male contacts and a 3.81 mm pitch. This single row, shrouded header features a durable glass filled polyester housing and copper alloy contacts plated with tin, ensuring excellent electrical performance and mechanical stability.
Designed for wire-to-board connection systems, this PCB header supports current up to 15A and voltage rating of 250V. Its through hole mount type facilitates robust PCB integration, recommended for PCB thickness of 1.0 to 1.6 mm.
Operating temperature ranges from -55°C to 105°C making it suitable for a variety of industrial, manufacturing, and electronic applications. The solder termination type with male contact gender ensures secure circuit assembly compliance.
Single row, 4 contacts with 3.81 mm pitch provides precise fit. Glass filled polyester housing improves thermal and mechanical resistance. Copper alloy contacts with tin plating ensure reliable conductivity. Through hole mounting enhances mechanical strength on PCB.
Wide operating temperature range supports diverse environments. Compatible with D-3100 series housings for mating connections. Ideal for industrial electronics, manufacturing hardware, and power connectors.
This product supports professionals seeking dependable PCB connection components, suited for electronics manufacturing, repair, and design. Explore more PCB Headers and connectors in the Power Connectors category on EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a maximum current of 15A.
The voltage rating is 250V.
This PCB header uses a through hole mounting type, suitable for robust PCB integration.
The housing is made of glass filled polyester, and the contacts are copper alloy with tin plating.
The pitch is 3.81 mm.
It operates within a temperature range of -55°C to 105°C.
This model features 4 male contacts.
The termination type is solder, which ensures secure circuit assembly.
Yes, it is compatible with D-3100 series housings for mating connections.
The orientation is straight, designed for straightforward installation.
It is suitable for industrial electronics, manufacturing hardware, and power connectors.
The country of origin for this product is India.
