TE Connectivity AMP-LATCH Series Right Angle Through Hole PCB Header 6 Contacts 2.54 mm Pitch 2 Row Shrouded 2-1761607-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | AMP-LATCH |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -65°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 718-9197Brand: TE ConnectivityManufacturers Part No.: 2-1761607-1 |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Low profile design suitable for space-saving PCB layouts.
- Military and centre polarization ensure reliable mating and reduced misconnection.
- Ejector latches provide secure connection and easy removal of mating IDC ribbon cable connectors.
- Constructed with polybutylene terephthalate housing and phosphor bronze contacts plated with gold for durability and conductivity.
- Operates reliably from -65°C to 105°C, supporting a voltage rating of 250V and current up to 1A.
- Right angle through hole mount type ensures stable PCB attachment and wire-to-board connection system.
- Suitable for applications in PCs, business and medical equipment, storage, networking, industrial controls, appliances, and electrical testing.
Product Description
TE Connectivity 2-1761607-1 AMP-LATCH Series Right Angle Through Hole PCB Header is a robust electronic connector designed for wire-to-board applications requiring reliable and secure mating.
Featuring 6 gold-plated phosphor bronze contacts arranged in 2 rows with 2.54 mm pitch, this shrouded right angle header supports a current rating of 1A and operates within a temperature range of -65°C to 105°C and voltage rating of 250V, ensuring dependable performance in demanding industrial and commercial environments.
The housing made of polybutylene terephthalate offers mechanical stability and resistance to environmental factors. The board-mounted through hole termination ensures stable physical and electrical connections, while the ejector latches facilitate secure engagement and easy disengagement from mating IDC ribbon cable receptacles.
The AMP-LATCH headers are available with either long or short latch styles; this particular model features secure latches providing mechanical polarization and preventing mismating, essential for equipment reliability.
Applications span a wide range of industries including computer systems, business and medical devices, data storage and networking equipment, industrial control systems, appliances, and electrical testing instruments.
Low profile design suitable for compact PCB layouts. Military and centre polarization for correct mating. Ejector latches enable secure yet easy connection and removal. Durable polybutylene terephthalate housing and gold-plated phosphor bronze contacts.
Operating temperature range from -65°C to 105°C and voltage rating of 250V. Through hole right angle mounting for stable connection. Wire-to-board connector system for reliable interfacing.
Enhance your electronic assemblies’ reliability and performance with this precision-engineered PCB header from TE Connectivity. Explore more PCB Headers and connectors in EnvMart’s electronic components section for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this PCB header is 250V.
This model operates reliably within a maximum temperature of 105°C.
It features 6 contacts arranged in 2 rows.
The pitch size of the contacts is 2.54 mm.
This header uses a through hole mounting type for stable PCB attachment.
The housing is made of polybutylene terephthalate, and the contacts are phosphor bronze plated with gold.
The current rating for this PCB header is 1A.
This model has a right angle orientation.
It supports a wire-to-board connector system.
Yes, it features military and center polarization to ensure reliable mating and reduce misconnection.
This header is suitable for applications in PCs, medical equipment, networking, industrial controls, and electrical testing.
The contact gender of this PCB header is male.
