Murata Power Solutions 2.2 mH Bobbin Inductor Radial Lead, Max SRF 0.7 MHz, Q 33, 1.2 A IDC, 700 mΩ RDC 1422512C

Murata Power Solutions 1422512C Bobbin Inductor is a high-performance passive electronic component designed for power line applications such as switching regulators, filters, and suppression circuits. It features an inductance of 2.2 mH with a tolerance of ±10%, supporting reliable and stable electrical performance.

This radial lead inductor can handle a maximum DC current of 1.2 A, making it suitable for high current environments. The device has a maximum DC resistance of 700 mΩ to minimize power loss while maintaining efficiency. Constructed from a high saturation flux density material, it can sustain high current without magnetic saturation, enhancing durability and performance.

Operating temperature ranges from -40°C to 85°C, allowing application in harsh industrial and commercial environments. With a maximum self-resonant frequency of 0.7 MHz and a minimum quality factor of 33, it ensures optimal energy storage and low loss characteristics. The radial lead termination style includes easy-strip pre-tinned enamelled copper leads with a 0.6 mm lead diameter and 10 mm lead length, facilitating straightforward PCB or chassis mounting with a central fixing hole.

The physical dimensions measure 27.1 mm in length, 24.4 mm in diameter, 20 mm in height, and 25.9 mm in depth. The product belongs to the Murata 1400 series, known for high current radial inductors. It is RoHS compliant, meeting environmental standards for lead-free electronic components.

This inductor is suitable for industrial, commercial, and manufacturing applications requiring reliable, high current radial inductors. Its robust design supports use in power management, signal filtering, and suppression circuits within electronic devices and systems.

Choose this Murata Power Solutions 1422512C 2.2 mH Bobbin Inductor for superior electrical performance and durability in your PCB and chassis assemblies. Explore more power Inductors and related components at EnvMart for your electronic component needs.

Inductance value of 2.2 mH with ±10% tolerance assures performance stability. Maximum DC current rating of 1.2 A enables reliable operation in power circuits. Maximum DC resistance is 700 mΩ, balancing efficiency and heat generation.

Constructed with high saturation flux density material for high current use. Operates across a temperature range from -40°C to 85°C for diverse environments. Maximum self-resonant frequency is 0.7 MHz, suitable for switching regulator filters.

Radial lead termination with 0.6 mm lead diameter and 10 mm lead length for ease of PCB mounting. Physical dimensions: length 27.1 mm, diameter 24.4 mm, height 20 mm, depth 25.9 mm. Minimum quality factor of 33 supporting efficient energy storage and minimal losses.

RoHS compliant ensuring environmental safety standards. Discover the full range of Murata Power Solutions and other industrial electronic components at EnvMart.
