TE Connectivity Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header 2 Contacts 4.14 mm Pitch 1 Row 1-770872-0

TE Connectivity 1-770872-0 Mini-Universal MATE-N-LOK Series Straight Through Hole PCB Header is a high-quality 2-contact, 1-row connector featuring a 4.14 mm pitch, optimized for wire-to-board applications.

Constructed with a shrouded white nylon housing rated to UL94V-0 standards, this header ensures excellent durability and flame resistance. It includes brass contacts plated with tin which provide superior electrical conductivity and corrosion protection. The connector is designed to operate reliably within a temperature range of -55°C to 105°C and supports a current capacity of 9.5 amperes and a voltage rating of 600 volts.

The 3.69 mm tail pin length facilitates secure solder termination on printed circuit boards, and the straight orientation of the single row aids in reliable and stable connections. This connector features a positive locking latch mechanism to maintain secure mating and board retention, making it suitable for demanding electronic and industrial applications.

TE Connectivity's Mini-Universal MATE-N-LOK connectors are specifically designed to improve manufacturing reliability and efficiency, providing high-quality electrical connections in a compact form factor. These headers are ideal for use in industries including electronics manufacturing, power systems, instrumentation, and control equipment, where consistent performance under varied environmental conditions is essential.

The header is manufactured from UL94V-0 nylon housing for enhanced flame retardancy and mechanical stability. Includes brass contacts with tin plating, ensuring excellent conductivity and longevity. Supports a current rating of 9.5A and a voltage rating up to 600V, compliant with industry standards.

Mounts through-hole on PCBs with a 4.14 mm pitch and single row configuration for secure placement. Designed with a positive locking latch mechanism for secure electrical mating and retention. Accommodation for wire-to-board connections, facilitating efficient assembly processes.

Exhibits robust performance over a wide temperature range (-55°C to 105°C) to meet industrial demands. Available with or without drain holes for various application requirements as per product part numbers. Widely applicable in industrial automation, power distribution, instrumentation, and telecommunications.

Part of the reliable MATE-N-LOK series from TE Connectivity, recognized globally for connector quality. Explore EnvMart's selection of TE Connectivity PCB Headers and related connectors for comprehensive wiring and mounting solutions.
