Texas Instruments Voltage Level Shifter 4 Voltage Level Translator 14-Pin TSSOP TXS0104EPWR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.15mm |
| Length | 5mm |
| Model | TXS0104EPWR |
| Mount Type | Surface |
| Output type | Open Drain |
| Series | TXS0104E |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 709-8745Brand: Texas InstrumentsManufacturers Part No.: TXS0104EPWR |
| Pin Count | 14 |
| Number of Elements per Chip | 4 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | Translator |
| Logic Function | Voltage Level Translator |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | -0.02mA |
| Maximum Propagation Delay Time @ CL | 6.8ns |
| Direction Type | Bi-Directional |
| Maximum Low Level Output Current | 1mA |
| Translation | Voltage Level |
Key Features
- Supports bi-directional voltage level translation with 4 channels per chip.
- Operates within a supply voltage range of 1.65V to 5.5V.
- Has a maximum propagation delay time of 6.8 nanoseconds for efficient signal handling.
- Features open drain output type suitable for various digital logic interfacing.
- Compact 14-pin TSSOP surface mount package with 1.15 mm height and 5 mm length.
- Supports temperatures from -40°C to 85°C for industrial applications.
- Maximum low level output current is 1 mA and maximum high level output current is -0.02 mA.
- Compliant with standard electrical specifications without automotive certification.
Product Description
Texas Instruments TXS0104EPWR is a reliable voltage level translator designed for bidirectional voltage level shifting across four independent channels. Packaged in a compact 14-pin Thin Shrink Small Outline Package (TSSOP), this surface mount device operates efficiently with a minimum supply voltage of 1.65 volts and a maximum supply voltage of 5.5 volts.
It offers a maximum propagation delay time of 6.8 nanoseconds at the specified load capacitance, ensuring swift data signal translation between circuits operating at different voltage levels. The device features open drain output type, allowing flexible interfacing in complex electronic systems.
This translator IC supports industrial-grade temperature ranges from -40°C to 85°C, making it suitable for various electronic, industrial, HVAC, and laboratory applications requiring precise voltage level adjustments.
Its physical dimensions of 1.15 mm height and 5 mm length enable integration into compact circuit boards. The device includes four elements per chip and a pin count of 14, perfectly suited for multi-channel voltage-level translation tasks.
While it lacks automotive-specific certification, it adheres to standard semiconductor electrical performances to ensure stable and safe operation. Supports bi-directional voltage level translation with four channels. Operates over a wide supply voltage range from 1.65V to 5.5V.
Maximum propagation delay of 6.8 ns enhances signal integrity. Compact TSSOP surface mount package ideal for dense circuit assembly. Open drain outputs for flexible interfacing in digital circuits. Wide operating temperature range from -40°C to 85°C.
Four elements integrated per chip with 14-pin configuration.
This Texas Instruments TXS0104EPWR Voltage Level Shifter is essential for industrial, laboratory, electronics manufacturing, and various semiconductor applications requiring efficient voltage translation.
Explore more semiconductor and logic IC products at EnvMart to meet your design and production requirements.
