onsemi Voltage Level Shifter Buffer 1 Buffer 5-Pin SC-70 FXLP34P5X
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1mm |
| Length | 2mm |
| Model | FXLP34P5X |
| Mount Type | Surface |
| Output type | Voltage |
| Series | FXLP34 |
| Maximum Operating Temperature | 85°C |
| Package Type | SC-70 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 5 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 3.6V |
| Logic Family | FXLP |
| Logic Function | Buffer |
| Minimum Supply Voltage | 1V |
| Maximum High Level Output Current | -2.6mA |
| Maximum Propagation Delay Time @ CL | 41ns |
| Direction Type | Uni-Directional |
| Maximum Low Level Output Current | 2.6mA |
| Translation | Buffer |
Key Features
- Operates with a minimum supply voltage of 1V and maximum supply voltage of 3.6V.
- Maximum propagation delay time at load capacitance (CL) is 41 nanoseconds ensuring quick signal shifting.
- Supports a maximum low level output current of 2.6mA and high level output current of -2.6mA.
- Designed for surface mounting with a small form factor measuring 2mm in length and 1mm in height.
- Operates reliably from -40°C to 85°C suitable for various industrial conditions.
- Provides voltage translation buffering with a logic family designation FXLP.
- Has one element per chip and 5 pins for connectivity.
- Lacks any automotive grading or special standards approval but is a robust standard component.
Product Description
onsemi FXLP34P5X is a uni-directional voltage level shifter buffer IC that facilitates voltage translation for electronic components, helping maintain signal integrity across different supply voltages. It belongs to the FXLP logic family and employs a buffer logic function to translate voltage levels effectively. Its compact SC-70 surface mount package contains 5 pins and one buffer element per chip.
This IC operates efficiently with supply voltages ranging from 1V to 3.6V and features a maximum propagation delay of 41 nanoseconds under load capacitance conditions. The device is rated for output currents of up to 2.6mA (both low and high level) ensuring stable interfacing with other components. Dimensions of the package are 2mm length and 1mm height, making it suitable for compact PCB designs.
The FXLP34P5X is designed for industrial environments with operating temperature range from -40°C to 85°C. Although not automotive certified, it meets standard semiconductor requirements for voltage translation tasks in power management, logic level conversion, and signal buffering. Applications include use in industrial tools, electronic components, and semiconductors sectors.
Minimum supply voltage 1V allows low voltage operation. Maximum propagation delay time 41ns ensures fast switching. Surface mount technology facilitates automated assembly. Compact 5 pin SC-70 package optimizes PCB space.
Wide operating temperature range for industrial use. Uni-directional voltage level shifting for signal consistency. Logic buffer function improves signal integrity. One element per chip ensures straightforward design integration.
This Voltage Level Shifter buffer is an essential component for designers needing efficient voltage translation with minimal delay and footprint. It supports a variety of industrial and manufacturing applications including power and connector interface circuits. Explore more electronic semiconductors and logic ICs at EnvMart for advanced component sourcing.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It operates with a minimum supply voltage of 1V and a maximum supply voltage of 3.6V.
The maximum propagation delay time at load capacitance is 41 nanoseconds, ensuring quick signal shifting.
It supports a maximum low level output current of 2.6mA and a high level output current of -2.6mA.
The package measures 2mm in length and 1mm in height, making it suitable for compact PCB designs.
It operates reliably from -40°C to 85°C, suitable for various industrial conditions.
This model has 5 pins for connectivity.
It belongs to the FXLP logic family and employs a buffer logic function for voltage translation.
It lacks any automotive grading or special standards approval, making it a standard component for non-automotive applications.
It is designed for surface mounting, which facilitates automated assembly.
There is one element per chip in the FXLP34P5X.
It is suitable for voltage translation tasks in power management, logic level conversion, and signal buffering in industrial tools and electronic components.
It is a uni-directional voltage level shifter, facilitating signal consistency across different supply voltages.
