Panasonic Hinge Lever Micro Switch Left Angle PCB Terminal 5A 250V ac SPCO AVM37253-A

Name: Panasonic Hinge Lever Micro Switch Left Angle PCB Terminal 5A 250V ac SPCO AVM37253-A
Brand: Panasonic
SKU: 352368
Price: 2.83 USD
Availability: InStock



Category Micro Switch Brand Panasonic Condition New

Specifications

Country of Origin	Thailand
Brand	Panasonic
Model	AVM37253-A
Series	AVM
Maximum Operating Temperature	85°C
Contact Configuration	SPCO
Actuator Type	Hinge Lever
Minimum Operating Temperature	-25°C
Terminal type	Left Angle PCB Terminal
Standards/Approvals	CSA, RoHS, SEMKO, UL, VDE
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	699-4784Brand: PanasonicManufacturers Part No.: AVM37253-A
Switch Contact Current	5A
Operating Force	0.54N
Mechanical Life	10Operations
Contact AC Voltage	250V ac
Microswitch Type	Subminiature

Key Features

The switch offers high precision flux resistant construction for reliable operation.
It accommodates a mechanical life expectancy of 10 million operations.
Suitable operating temperature ranges from -25°C to 85°C for varied environments.
Complies with CSA, RoHS, SEMKO, UL, and VDE standards ensuring safety and quality.
Typical uses include communication equipment, vending machines, security systems, and medical devices.
The subminiature design supports compact PCB mounting with long and reliable electrical life.

Product Description

Panasonic AVM37253-A is a subminiature micro switch with a hinge lever actuator and left angle PCB terminal design. It supports a switch contact current of 5A at 250V ac and features SPCO contact configuration for reliable switching performance. This model is engineered for industrial and automation applications requiring precise and durable switching components.

Its construction includes flux resistant terminals molded integrally for longevity and reliability, offering a long mechanical life of 10 million operations and an extended electrical life, depending on contact type. The operating force is low at 0.54 N, making it responsive to actuation.

Designed for industrial environments, it functions safely across a temperature range from -25°C to 85°C. It complies with multiple international standards such as CSA, RoHS, SEMKO, UL, and VDE, affirming its quality and safety compliance.

Common applications include communication electronics, vending machines, security systems, data systems, and medical equipment where small, precise, and reliable switching is essential. Its subminiature size allows installation even in compact spaces.

Manufactured in Thailand as part of the AVM series, this switch combines durability and precision essential for industrial automation and electronic control systems. The hinge lever actuator and left angle PCB terminal design accommodate versatile mounting and actuation requirements.

The switch offers high precision flux resistant construction for reliable operation. Includes a mechanical life expectancy of 10 million operations ensuring durability. Supports a 5A contact current at 250V ac voltage. Operating temperature ranges from -25°C to 85°C for flexible usage environments.

Certified by CSA, RoHS, SEMKO, UL, and VDE for safety and standards compliance. Ideal for use in communication, security, vending, and medical devices. Explore further within the Micro Switch category on EnvMart for complementary components and related switching devices.
