MaxLinear 2-Channel Line Transceiver TTL Inverting 28-Pin TSSOP SP3238EEY-L/TR

MaxLinear SP3238EEY-L/TR is a 2-Channel Line Transceiver IC engineered for RS-232 serial communication interfaces. Featuring CMOS/TTL logic compatibility and TTL output, it enables robust data transmission and reception with inverting polarity.

This device is housed in a 28-pin TSSOP surface-mount package, allowing easy integration into compact electronic designs. It supports a supply voltage range from 3V to 5.5V, making it adaptable to diverse power environments.

With a maximum propagation delay time of 150 nanoseconds under capacitive load, the transceiver ensures timely data handling for communication systems. Its operating temperature spectrum from -40°C to 85°C suits harsh industrial and commercial environments.

Physical dimensions include a length of 10.5 mm, width of 5.6 mm, and height of 2 mm, optimizing PCB space usage. The device consumes a minimal supply current of 1mA, promoting energy efficiency in application circuits.

This transceiver is ideal for industrial automation, embedded systems, communication equipment, and laboratory instrumentation requiring reliable RS-232 interfaces. It complies with electrostatic discharge robustness and compatibility with standard RS-232 devices.

Operates with CMOS/TTL logic family. Two communication channels provide simultaneous line transceiving. Offers inverting polarity for signal output. Compact 28-pin TSSOP surface-mount package design. Operating voltage range from 3V to 5.5V.

Supports temperature range of -40°C to 85°C for varied environments. Low power consumption with 1mA supply current. 150ns maximum propagation delay for efficient communication timing. Suitable for RS-232 communication standards and equipment.

Applicable in industrial, laboratory, and embedded system electronics. Explore more semiconductor and line interface IC products on EnvMart for your electronic component needs.
