onsemi 5 W 51 V Voltage Regulator Zener Diode Single 2-Pin Through Hole DO-15 1N5369BRLG
Specifications
| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 3.68mm |
| Length | 8.89mm |
| Model | 1N5369BRLG |
| Mount Type | Through Hole |
| Series | 1N53 |
| Maximum Operating Temperature | 200°C |
| Package Type | DO-15 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 5W |
| Diode Configuration | Single |
| Test Current It | 25mA |
| Maximum Reverse Leakage Current | 500nA |
| Nominal Zener Voltage Vz | 51V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 27Ω |
Key Features
- This diode features a nominal Zener voltage of 51 volts with a ±5% tolerance.
- It has a maximum power dissipation rating of 5 watts for reliable operation.
- The device is configured as a single element with a 2-pin count for through hole mounting.
- The maximum Zener impedance is specified at 27 ohms at the test current of 25 mA.
- It supports an operating temperature range from -65°C to 200°C for broad environmental tolerance.
- The diode’s maximum reverse leakage current is 500 nanoamperes ensuring low leakage under reverse bias.
- The package type is DO-15 with dimensions approximately 8.89 mm in length and 3.68 mm in height.
- This device is part of the 1N53 series by onsemi known for stable voltage regulation performance.
Product Description
onsemi 1N5369BRLG is a 5 Watt, 51 Volt Zener Diode featuring a single element configuration designed for voltage regulation applications. This diode is housed in a DO-15 package with through hole mounting and offers reliable performance in a range of industrial and electronic systems.
The diode supports a nominal Zener voltage of 51 volts with a tolerance of ±5%, enabling precise voltage regulation. It dissipates a maximum power of 5 watts and has an impedance of 27 ohms tested at a 25 mA current, making it suitable for protected voltage clamp circuits.
This component operates within a wide temperature range from -65°C to 200°C, ensuring durability and stability in varying environmental conditions. Its maximum reverse leakage current of only 500 nanoamperes also contributes to its efficiency and reliability.
The 2-pin DO-15 package measures 8.89 mm in length and 3.68 mm in height, suitable for through hole mounting on printed circuit boards. The 1N53 series diodes from onsemi are renowned for their improved operating characteristics and tight electrical limits.
Typical applications include power supplies, voltage regulation, and overvoltage protection in industrial, laboratory, and manufacturing electronics. This diode is a vital component for designers seeking robust and high-performance zener diode solutions.
Nominal Zener voltage 51 V with ±5% tolerance. Maximum power dissipation of 5 W for reliable performance. Single element diode with 2 pins for through hole mounting. Maximum Zener impedance of 27 Ω at 25 mA test current.
Operating temperature range: -65°C to 200°C for wide environmental suitability. Low maximum reverse leakage current of 500 nA to minimize power loss. Compact DO-15 package dimensions: 8.89 mm length, 3.68 mm height. Part of the 1N53 series designed for voltage regulation tasks.
Ideal for industrial electronics, power supply voltage clamps, and protection circuits. Explore more semiconductor and zener diode options with onsemi and similar leading brands available on EnvMart for specialized industrial and electronic component needs.
Explore more products in our Zener Diodes category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The nominal Zener voltage of this diode is 51 volts with a tolerance of ±5%.
It has a maximum power dissipation rating of 5 watts for reliable operation.
The maximum reverse leakage current is specified at 500 nanoamperes, ensuring low leakage under reverse bias.
The DO-15 package measures approximately 8.89 mm in length and 3.68 mm in height.
The maximum Zener impedance is specified at 27 ohms at a test current of 25 mA.
It supports an operating temperature range from -65°C to 200°C, ensuring broad environmental tolerance.
This diode has a 2-pin configuration for through hole mounting.
It is configured as a single element diode, designed for voltage regulation applications.
This diode is part of the 1N53 series by onsemi, known for stable voltage regulation performance.
It uses through hole mounting, making it suitable for installation on printed circuit boards.
Typical applications include power supplies, voltage regulation, and overvoltage protection in industrial and electronic systems.
The test current for measuring the Zener impedance is 25 mA.
