Wurth Elektronik WE-PD4 Unshielded Wirewound Surface Mount Inductor, 10 μH ±20% Inductance, 1.2 A Maximum DC 7445510

Wurth Elektronik 7445510 is a wirewound Surface Mount Inductor from the WE-PD4 series, designed for compactness and efficiency. This unshielded inductor features a ferrite core optimized for low loss at low frequencies with an inductance value of 10 microhenries (μH) with a tolerance of ±20%.

Rated to handle a maximum DC current of 1.2 amperes (A), it is ideal for applications such as high efficiency switched mode power supplies (SMPS) and electromagnetic interference (EMI) suppression systems.

The inductor complies with the AEC-Q200 automotive standard ensuring reliability in automotive electronic equipment. Its operating temperature range extends from -40°C to 100°C, making it suitable for demanding environments.

With a maximum DC resistance of 160 milliohms (mΩ) and a maximum self-resonant frequency of 35 MHz, it performs well at higher frequencies.

The termination style is surface mount, facilitating straightforward integration onto printed circuit boards using standard SMT assembly processes. The physical dimensions of the inductor are 6.6 mm in length, 2.92 mm in height, and 4.45 mm in depth, supplied in a reel packaging format to support production efficiency.

Unshielded wirewound construction with ferrite core provides low inductance loss. 10 μH inductance with ±20% tolerance and 1.2 A maximum DC current rating. Designed for high efficiency SMPS and interference suppression applications.

Meets AEC-Q200 automotive qualification and RoHS LF standards. Operating temperature range from -40°C to 100°C for reliable performance. Compact size enables use in space-constrained PCB layouts. Reel packaging supports automated manufacturing processes.

This inductor is primarily used in industrial electronics, automotive power systems, telecommunications equipment, and general electronic circuit design, where compact, reliable inductors are required. Use the Wurth Elektronik category on EnvMart to find compatible inductors, components, and accessories.
