Broadcom Through Hole Optocoupler 8-Pin PDIP, Transistor Output, 1 Channel, Isolation Voltage 3750V ac HCPL-7800-000E

Broadcom HCPL-7800-000E is a high-performance optocoupler featuring a single channel with transistor output, housed in an 8-pin PDIP package. Designed primarily for electrical isolation purposes, it enables precise signal transfer while maintaining safety and compliance with industry standards.

This optocoupler offers an isolation voltage of 3750V ac and operates efficiently across a temperature range from -40°C to 100°C, making it suitable for industrial, electronic components manufacturing, instrumentation, and power control applications.

The typical rise and fall time of 6.6 microseconds ensures rapid switching capabilities, enhancing overall circuit responsiveness. The device meets rigorous standards including UL 1577, CSA, and VDE 0884, guaranteeing reliability and safety in demanding environments.

Its through hole mounting style and 8-pin PDIP package allow for straightforward assembly in various printed circuit boards, supporting efficient production processes. Single channel optocoupler with transistor output for precise signal isolation.

3750V ac isolation voltage for robust electrical separation. Nominal rise and fall times of 6.6 microseconds for fast switching. Operating temperature range from -40°C to 100°C for versatile use. Compliance with UL 1577, CSA, and VDE 0884 standards ensuring safety.

Through hole mount type facilitating easy PCB installation. 8-pin PDIP package type for compatibility with common circuit designs. Maximum input current capped at 670 nA to minimize power draw.

This product is ideal for use in electronics manufacturing, power supply isolation, industrial instrumentation, and other applications requiring reliable electrical separation. Broadcom’s HCPL series is trusted for its consistent performance and safety compliance.
