Broadcom DC Input Optocoupler Through Hole 8-Pin DIP HCPL-J312-000E
Specifications
| Country of Origin | India |
|---|---|
| Brand | Broadcom |
| Model | HCPL-J312-000E |
| Packaging | Tape & Reel |
| Mount Type | Through Hole |
| Output type | Transistor |
| Series | HCPL |
| Maximum Operating Temperature | 100°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 16mA |
| Number Of Channels | 1 |
| Standards/Approvals | CSA, IEC/EN/DIN EN 60747-5-5, UL 1577 |
| Maximum Forward Voltage | 1.95V |
| Number of Pins | 8 |
| Input Current Type | DC |
| Typical Rise Time | 0.1μs |
| Isolation Voltage | 3750V ac |
Key Features
- High isolation voltage of 3750V AC provides excellent electrical isolation.
- Fast switching times with typical rise and fall times of 0.1 microseconds.
- Input forward voltage maximum rated at 1.95V ensures efficient operation.
- Maximum input current of 16mA for input side operation.
- Operates reliably from -40°C up to 100°C for industrial temperature ranges.
- Output type is transistor with logic output capability suitable for gate driving.
- Package is 8-pin DIP suitable for through hole mounting and tape & reel packaging.
- Complies with standards including CSA, IEC/EN/DIN EN 60747-5-5, and UL 1577 for safety and quality.
Product Description
Broadcom HCPL-J312-000E is a high-performance DC input optocoupler designed with an 8-pin DIP through hole package. It is optimized for electrical isolation and fast gate driving applications. The device features a high isolation voltage of 3750V AC, ensuring safe signal isolation between input and output circuits in sensitive electronic systems.
This optocoupler includes a transistor output type providing logic compatible switching suitable for driving IGBT and Power MOSFET transistors in motor control, power conversion, and industrial automation applications. It exhibits fast switching speeds, with typical rise and fall times of 0.1 microseconds, making it ideal for high-speed signal isolation.
The device supports input forward voltage up to a maximum of 1.95V and maximum input current of 16mA, facilitating efficient and reliable input signal operation. It operates in a wide temperature range from -40°C to 100°C, suitable for varied industrial environments. Its construction complies with relevant safety standards such as CSA, IEC/EN/DIN EN 60747-5-5, and UL 1577, ensuring reinforced insulation and quality assurance.
The HCPL-J312-000E is packaged in a DIP 8-pin form factor designed for through hole mounting and is supplied on tape & reel, supporting automated assembly processes. This product is suitable for industrial automation, motor control systems, power conversion equipment, and other situations where signal isolation and protection are critical.
High isolation voltage ensures electrical safety. Fast switching times improve efficiency in control circuits. Wide operating temperature supports industrial applications. Transistor output for reliable logic level signal switching.
Complies with major electrical standards. Through hole 8-pin DIP package suitable for PCB mounting. Tape & reel packaging enables automated manufacturing. Explore the Electronics & Electricals category for more Optocoupler solutions and advanced electronic components at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The isolation voltage of this model is 3750V AC, providing excellent electrical isolation between input and output circuits.
The maximum input current for the HCPL-J312-000E is 16mA, which allows for efficient operation on the input side.
This model has a typical rise time of 0.1 microseconds, enabling fast switching speeds for high-speed applications.
The HCPL-J312-000E operates reliably in a temperature range from -40°C to 100°C, making it suitable for industrial applications.
This model features a transistor output type that is compatible with logic-level switching, suitable for driving IGBT and Power MOSFET transistors.
It is packaged in an 8-pin DIP form factor and supplied on tape & reel, which facilitates automated assembly processes.
This optocoupler complies with CSA, IEC/EN/DIN EN 60747-5-5, and UL 1577 standards, ensuring safety and quality.
This model has a single channel, making it suitable for various applications requiring signal isolation.
The maximum forward voltage for the input is rated at 1.95V, allowing for efficient input signal operation.
This optocoupler is designed for through hole mounting, which is common in many PCB applications.
The HCPL-J312-000E is part of the HCPL series of optocouplers, which are optimized for high-performance applications.
The country of origin for this model is India, indicating its manufacturing location.
