Broadcom DC Input Optocoupler Through Hole, Transistor Output, 8-Pin DIP HCPL-J312-000E

Broadcom HCPL-J312-000E is a DC input optocoupler with transistor output, housed in an 8-pin DIP package suited for through hole mounting. It is optimized for isolated gate driving of IGBT and Power MOSFET transistors, providing essential protection by isolating logic signals from high voltages.

This optocoupler features rapid switching speeds with typical 0.1μs rise and fall times, enabling efficient gate control in high-frequency switching applications. Its 3750V AC isolation voltage ensures reinforced insulation meeting stringent industrial safety standards, making it well-suited for demanding environments.

The device supports a maximum input current of 16mA and a maximum forward voltage of 1.95V, ensuring compatibility with standard input drivers. Rated to operate reliably from -40°C to 100°C, it delivers consistent performance across wide temperature ranges common in industrial and automotive applications.

Broadcom’s HCPL-J312-000E meets key certifications including CSA, IEC/EN/DIN EN 60747-5-5, and UL 1577, reinforcing its reliability and safety credentials. The transistor output and logic output capabilities enable seamless integration with digital and power control circuitry.

Ideal for use in industrial motor control, power conversion, and other applications demanding precise switching and electrical isolation, this optocoupler combines high common mode rejection and rail-to-rail output performance.

Enables isolated gate drive for IGBT and Power MOSFET transistors. Exhibits fast switching with 0.1 microseconds rise and fall times. Provides high isolation voltage up to 3750V AC for safety and noise immunity. Operates effectively within a wide temperature range from -40°C to 100°C.

Features logic output compatibility for seamless integration into digital circuits. Packaged in tape and reel format suitable for automated assembly processes. Certified to CSA, IEC/EN/DIN EN 60747-5-5, and UL 1577 standards ensuring quality and reliability.

Designed with rail-to-rail output and high common mode rejection for enhanced performance. Ideal for motor control and power conversion applications requiring reinforced insulation. Explore more products in the Optocoupler category at EnvMart to find complementary electronic components for your industrial and commercial projects.
