Broadcom DC Input Optocoupler Through Hole 8-Pin DIP HCPL-2200-000E
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Broadcom |
| Model | HCPL-2200-000E |
| Packaging | Tape & Reel |
| Mount Type | Through Hole |
| Series | HCPL |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Maximum input current | 5mA |
| Number Of Channels | 1 |
| Standards/Approvals | CSA, IEC/EN/DIN EN 60747-5-2, UL1577 |
| Maximum Forward Voltage | 1.75V |
| Number of Pins | 8 |
| Input Current Type | DC |
| Typical Rise Time | 55ns |
| Typical Fall Time | 15ns |
| Isolation Voltage | 3750V ac |
Key Features
- Features a maximum forward voltage of 1.75V ensuring efficient signal transmission.
- Equipped with one channel and 8 pins in a DIP package for convenient PCB mounting.
- Operates with a maximum input current of 5mA and DC input current type for stable performance.
- Offers a high isolation voltage of 3750V AC for protecting circuits in industrial and electronic applications.
- Functional within a wide temperature range from -40°C to 85°C for versatile environmental conditions.
- Typical rise and fall times of 55ns and 15ns respectively enable fast switching operations.
- Complies with CSA, IEC/EN/DIN EN 60747-5-2 and UL1577 standards for quality and safety assurance.
- Packaged in tape & reel format facilitating automated assembly processes.
Product Description
Broadcom HCPL-2200-000E is a DC input optocoupler designed for through hole mounting, featuring an 8-pin DIP package. It is engineered to provide high-speed and reliable electrical isolation between input and output signals in electronic circuits. This component is widely used in industrial electronics, power supplies, signal isolation, and control systems.
The optocoupler supports a maximum forward voltage of 1.75V, with a maximum input current of 5mA, while operating on DC input current. The device ensures high isolation voltage rated at 3750V AC, making it suitable for applications requiring stringent isolation between high voltage and low voltage sections.
Its typical rise time of 55ns and fall time of 15ns allow fast switching, essential for digital communication and signal processing tasks. The product meets recognized standards including CSA, IEC/EN/DIN EN 60747-5-2, and UL1577, confirming its safety and performance in demanding environments.
The operating temperature range from -40°C to 85°C allows use in diverse environmental conditions, including harsh industrial settings. Packaged in tape & reel, the HCPL-2200-000E facilitates automated mounting on PCBs, improving manufacturing efficiency.
Maximum forward voltage of 1.75V enables efficient signal transfer. One channel with 8 pins in a DIP package for easy PCB integration. Maximum input current of 5mA ensures stable input power requirements. Isolation voltage of 3750V AC provides high electrical isolation.
Wide operating temperature from -40°C to 85°C supports versatile applications. Fast switching with typical rise/fall times of 55ns/15ns improves signal integrity. Compliance with CSA, IEC/EN/DIN EN 60747-5-2, UL1577 standards guarantees quality.
Tape & reel packaging supports automated manufacturing processes. Made in Thailand under new product condition. This optocoupler is ideal for industrial, laboratory, electronic manufacturing and automation systems where electrical isolation and signal fidelity are critical.
Explore more from Broadcom and similar high-performance Optocouplers in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum forward voltage of the Broadcom HCPL-2200-000E is 1.75V, which ensures efficient signal transmission.
It has a high isolation voltage rating of 3750V AC, providing significant electrical isolation between input and output signals.
This optocoupler operates within a temperature range of -40°C to 85°C, making it suitable for diverse environmental conditions.
It features one channel, which is designed for reliable signal isolation in electronic circuits.
The typical rise time is 55ns and the fall time is 15ns, allowing for fast switching operations.
The maximum input current for this model is 5mA, ensuring stable performance during operation.
It is packaged in tape & reel format, which facilitates automated assembly processes in manufacturing.
The HCPL-2200-000E complies with CSA, IEC/EN/DIN EN 60747-5-2, and UL1577 standards for safety and performance assurance.
This model is designed for through hole mounting, which is suitable for various PCB applications.
The package type is DIP (Dual In-line Package), which has 8 pins for easy integration into circuits.
It is manufactured in Thailand, ensuring compliance with international manufacturing standards.
This optocoupler is widely used in industrial electronics, power supplies, signal isolation, and control systems.
