onsemi Zener Diode Single 5.6 V 500 mW Surface Mount 2-Pin SOD-123 MMSZ5V6T1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Zener Diode Single 5.6 V 500 mW Surface Mount 2-Pin SOD-123 MMSZ5V6T1G

Name: onsemi Zener Diode Single 5.6 V 500 mW Surface Mount 2-Pin SOD-123 MMSZ5V6T1G
Brand: onsemi
SKU: 341472
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	3.86mm
Model	MMSZ5V6T1G
Mount Type	Surface
Series	MMSZxxxT1G
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	1μA
Nominal Zener Voltage Vz	5.6V
Zener Type	Voltage Regulator
Maximum Zener Impedance	40Ω
Surface Mount case	SOD-123
5.6V Zener diode,MMSZ5V6 500mWBrand	ON Semiconductor

Key Features

Zener diode designed for voltage regulation with 5.6 V nominal voltage.
Maximum power dissipation of 500 mW suitable for low power applications.
Compact 2-pin surface mount SOD-123 package for PCB integration.
Wide operating temperature range from -55°C to 150°C for reliability.
Low maximum reverse leakage current of 1 microampere for efficiency.
Maximum Zener impedance of 40 ohms ensures stable voltage regulation.
RoHS compliant for environmental safety and standards adherence.
Test current specified at 5 mA for accurate operation.

Product Description

onsemi MMSZ5V6T1G is a discrete semiconductor Zener diode designed for voltage regulation applications within electronic circuits. This device incorporates a single diode element in a compact 2-pin SOD-123 surface mount package, allowing for easy integration on printed circuit boards with limited space.

The diode provides a nominal Zener voltage of 5.6 V with ±5% tolerance, making it ideal for fixed voltage regulation in low power scenarios. Its power dissipation rating is 500 mW, supporting efficient thermal handling under normal operating conditions.

Temperature tolerance ranges from -55°C to 150°C, making it suitable for industrial, automotive, and consumer electronic use cases where environmental conditions may vary. The diode's maximum Zener impedance of 40 ohms ensures stable voltage regulation during operation with a test current of 5 mA.

This Zener diode is RoHS compliant, reflecting adherence to international environmental standards. The compact surface mount design (SOD-123) with a height of 1.35 mm and length of 3.86 mm facilitates compact PCB layouts.

This diode is used primarily for voltage stabilization and protection circuits in industrial machinery, power supplies, automotive electronics, and consumer devices. The device's low maximum reverse leakage current of only 1 microampere guarantees minimal current loss and high efficiency for sensitive circuitry.

Its 2-pin configuration supports straightforward soldering and mounting processes, reducing manufacturing complexity. Suitable for various semiconductor-based electronic projects requiring precise voltage regulation in a compact footprint.

Designed for reliable long-term performance under rigorous industrial and commercial conditions. EnvMart customers can browse additional onsemi semiconductor and Zener diode products for diverse industrial applications.
