Nexperia Schmitt Trigger Inverter Logic IC with 3 Schmitt Trigger Inputs 0.8V-3.6V Supply 74LVC1G14GX4-Q100Z

Nexperia 74LVC1G14GX4-Q100Z is a high-performance Schmitt Trigger Inverter Logic IC designed with CMOS technology, featuring three Schmitt trigger inputs and optimized for low power consumption. Operating from a supply voltage range of 0.8 V to 3.6 V, it delivers reliable switching with a maximum propagation delay time of 7 ns, making it suitable for a variety of industrial and electronic applications.

This device is surface-mount type with compact dimensions of 650μm in length and width, and a height of 350μm, allowing integration into dense circuitry with ease. It supports a wide operating temperature range from -55°C to 125°C, ensuring stability and performance in harsh environments such as automotive electronics, industrial controls, and instrumentation.

The integrated IOFF circuitry disables output during partial power down to prevent backflow current, enhancing power safety and device longevity. Its overvoltage tolerant inputs up to 3.6 V and high noise immunity make it robust under electrical noise conditions common in power supply and industrial environments. The latch-up immunity surpasses 100 mA per JESD 78 Class II standards, indicating strong reliability.

Applications include wave and pulse shaping circuits, astable and monostable multivibrators, making it an ideal component for timing and signal conditioning in electronic designs. The device complies with JEDEC and RoHS standards, guaranteeing compliance with quality and environmental requirements.

This Nexperia IC offers dependable logic inversion functionality combined with robust industrial-grade electrical characteristics, suitable for electronic component assemblies, automation systems, and semiconductor based circuit designs.

The device provides low static and dynamic power consumption across operating voltages. It has a maximum propagation delay time of 7 ns at capacitive load. Designed for surface mounting with compact dimensions. Supports operating temperatures from -55°C to 125°C, suitable for industrial applications.

Incorporates IOFF circuitry to prevent damaging backflow currents when powered down. Overvoltage tolerant inputs up to 3.6 V ensure robust noise immunity. Latch-up performance exceeds 100 mA per JESD 78 Class II standard.

Complies with JEDEC and RoHS standards, ensuring quality and environmental safety. Provides features like wave and pulse shaping, astable and monostable multivibrator functions. Explore more semiconductor and logic IC products from Nexperia at EnvMart for your industrial, laboratory, and electronic circuit needs.
