Vishay 2225 Shielded Surface Mount Inductor 680 nH ±20% 16.5 A Idc IHLE2525
Specifications
| Country of Origin | China |
|---|---|
| Brand | Vishay |
| Height | 3.23mm |
| Length | 7.21mm |
| Model | IHLE2525 |
| Depth | 3.23mm |
| Series | IHLE2525 |
| Maximum Operating Temperature | 155°C |
| Minimum Operating Temperature | -55°C |
| Inductance | 680nH |
| Standards/Approvals | RoHS |
| Package/Case | 2225 |
| Maximum DC Current | 16.5A |
| Maximum DC Resistance | 5.76mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 56.1MHz |
| Inductor Construction | Shielded |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 2225 package size with dimensions 7.21 mm length, 3.23 mm height, and 3.23 mm depth.
- High current inductor suitable for DC/DC energy storage up to 1 to 2 MHz frequencies.
- E-field shield integrated for maximum electromagnetic interference (EMI) reduction.
- Designed to operate within a temperature range of -55°C to 155°C.
- Meets automotive standard AEC-Q200 ensuring reliability in automotive applications.
- Surface mount termination style for efficient PCB integration.
- Low maximum DC resistance of 5.76 mΩ reducing power losses in circuits.
- RoHS compliant and moulded construction for durability and environmental safety.
Product Description
Vishay IHLE2525 is a high-performance shielded surface mount inductor designed for demanding electronic circuits. Featuring a 680 nH inductance with a tolerance of ±20%, it supports a maximum DC current of 16.5 A, making it ideal for power supply filtering and energy storage applications up to frequencies of 2 MHz.
This inductor comes in a compact 2225 package with dimensions of 7.21 mm length, 3.23 mm height, and 3.23 mm depth, suitable for surface mounting on printed circuit boards. Its integrated E-field shield maximizes EMI reduction, crucial for maintaining signal integrity in sensitive electronic components.
The product is built to endure harsh conditions with operation temperatures ranging from -55°C to 155°C and meets the AEC-Q200 standard required for automotive use, ensuring durability and reliability. Additionally, the inductor's low DC resistance of 5.76 mΩ results in minimal power loss and enhanced efficiency.
Constructed with a moulded design and RoHS compliance, this Vishay inductor is environmentally responsible and durable for extended service life. Its maximum self-resonant frequency of 56.1 MHz allows operation in high-frequency circuits.
Compact 2225 package dimensions for PCB integration. High current rating of 16.5 A to support robust power applications. Integrated shield for effective EMI suppression. Wide temperature range of -55°C to 155°C. Compliance with automotive industry standards AEC-Q200.
Low DC resistance to minimize energy losses. RoHS compliant for environmental safety. Moulded construction ensuring mechanical robustness. Maximum self-resonant frequency of 56.1 MHz for high-frequency operation.
This Surface Mount Inductor is suited for industrial, automotive, and consumer electronic applications requiring reliable, high current inductors with excellent EMI filtering capabilities. Explore Vishay inductors and related electronic components for efficient circuit design at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 680 nH with a tolerance of ±20%.
This model supports a maximum DC current of 16.5 A.
The dimensions of the 2225 package are 7.21 mm in length, 3.23 mm in height, and 3.23 mm in depth.
The maximum operating temperature for this inductor is 155°C.
Yes, it meets the automotive standard AEC-Q200 and is RoHS compliant.
The maximum self-resonant frequency of this inductor is 56.1 MHz.
The termination style of this model is surface mount, suitable for PCB integration.
The maximum DC resistance is 5.76 mΩ, which helps to reduce power losses in circuits.
This inductor can operate within a temperature range of -55°C to 155°C.
It features a shielded construction, which aids in electromagnetic interference (EMI) reduction.
This inductor is suitable for industrial, automotive, and consumer electronic applications requiring high current inductors with effective EMI filtering capabilities.
The country of origin for this inductor is China.
