Epson 26 MHz Crystal Unit ±9 ppm Surface Mount Technology 4-Pin 0.5 mm Height 2 mm Length 1.6 mm Width Q22FA1280055412

Free Delivery in India | Lowest Global Shipping Charges

Epson 26 MHz Crystal Unit ±9 ppm Surface Mount Technology 4-Pin 0.5 mm Height 2 mm Length 1.6 mm Width Q22FA1280055412

Name: Epson 26 MHz Crystal Unit ±9 ppm Surface Mount Technology 4-Pin 0.5 mm Height 2 mm Length 1.6 mm Width Q22FA1280055412
Brand: Epson
SKU: 337134
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Epson Condition New

Specifications

Country of Origin	India
Brand	Epson
Height	0.5mm
Operating Temperature Range	-40°C to +85 °C
Length	2mm
Model	Q22FA1280055412
Packaging	Tape & Reel
Width	1.6mm
Mount Type	Surface
Series	Q22FA
Maximum Operating Temperature	85°C
Package Type	SMT
Minimum Operating Temperature	-40°C
Standards/Approvals	RoHS
Pin Count	4
Standard Frequency	26MHz
Load Capacitance	12pF
Series Resistance	60Ω

Key Features

The device features a 4-pin SMT package measuring 2 mm in length, 1.6 mm in width, and 0.5 mm in height.
Operating temperature range spans from -40°C to +85°C, supporting robust performance in varied environments.
Load capacitance is specified at 12 pF, suitable for stable oscillation applications.
Series resistance is 60 Ω, minimizing energy loss during operation.
Meets RoHS compliance ensuring environmental safety standards are met.
Commonly used in mobile phones, Bluetooth devices, W-LAN, ISM band radios, and MPU clocks.

Product Description

Epson Q22FA1280055412 Crystal Unit is a precision electronic component operating at a standard frequency of 26 MHz with a frequency tolerance of ±9 ppm. It is designed as a surface mount technology unit with a compact 4-pin package suitable for high-density circuit assemblies.

This crystal unit has dimensions of 2 mm in length, 1.6 mm in width, and 0.5 mm in height, optimizing board space usage. The specified load capacitance of 12 pF enhances oscillator circuit stability for reliable timing and frequency control.

Operating temperature ranges from -40°C to +85°C, allowing it to perform reliably in harsh industrial, telecommunications, and consumer electronics environments. Its frequency stability of ±15 ppm and series resistance of 60 Ω contribute to high accuracy and efficiency.

The Epson Q22FA series is RoHS compliant, reflecting adherence to environmental and safety standards. Its applications include mobile phones, Bluetooth devices, wireless LAN, ISM band radio communication, and microprocessor unit (MPU) clock functions.

The unit’s compact SMT 4-pin design facilitates automated assembly and reduces overall device footprint. Engineered to withstand a broad range of operating temperatures ensuring versatile industrial and commercial use. Ensures high frequency accuracy and minimal signal distortion in crystal oscillator circuits.

Complies with environmental regulations making it suitable for green manufacturing programs. Ideal for portable and embedded device applications requiring consistent clock timing.

This crystal unit is part of the Epson Q22FA series, renowned for precision and reliability in electronic circuit designs. Suitable for lab testing, manufacturing processes, and integration in diverse electronic systems.

Explore additional Epson crystal units in the EnvMart electronic components catalog for complementary or alternate frequency needs.
