Panasonic Shielded Wirewound Surface Mount Inductor with Metal Composite Core 2.45μH ±20% 14.1A Idc ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5.4mm |
| Length | 8.5mm |
| Model | ETQP5M |
| Depth | 8mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 2.45μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 14.1A |
| Pin Count | 2 |
| Maximum DC Resistance | 8.14mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- The inductor features a metal composite core for enhanced stability and high heat resistance.
- Constructed with a shielded wirewound design to reduce electromagnetic interference.
- Ideal for high vibration environments with integral construction for durability.
- Operates reliably up to 150°C with low audible noise for noise-sensitive applications.
- Packaged in tape & reel format suitable for automated PCB insertion processes.
- Meets automotive standard AEC-Q200 ensuring quality for automotive electronics.
- Compact dimensions with 8.5mm length, 5.4mm height, and 8mm depth.
- Maximum DC resistance of 8.14 milliohms ensuring efficient current flow.
Product Description
Panasonic ETQP5M shielded wirewound surface mount inductor with metal composite core offers high reliability and stability with an inductance of 2.45μH ±20%, capable of handling a maximum DC current of 14.1A. The inductor is engineered for industrial and automotive electronics applications requiring compact size and high performance.
With a metal composite core and shielded construction, it minimizes electromagnetic interference while maintaining stable inductance over temperature variations. Its robust design includes integral construction that provides excellent vibration resistance, making it suitable for demanding HVAC, manufacturing, and automotive environments.
The device operates at temperatures up to 150°C, supporting peak current handling with low audible noise, which is beneficial for noise-sensitive electronic equipment. The compact surface mount package, with dimensions of length 8.5mm, height 5.4mm, and depth 8mm, fits seamlessly on modern PCBs.
Supplied in tape & reel packaging, the ETQP5M model supports efficient machine placement during assembly. It complies with automotive standard AEC-Q200 and RoHS environmental directives, ensuring its suitability for automotive and high-quality industrial applications.
Typical use cases include noise filtering in drive circuits, power supply regulation, and signal conditioning in industrial machinery, laboratory equipment, and automotive electronic systems.
The inductor features a metal composite core for enhanced stability and high heat resistance. Constructed with a shielded wirewound design to reduce electromagnetic interference. Integral construction ensures high vibration resistance for durability in harsh environments.
Operates reliably up to 150°C to handle high temperature applications. Complies with automotive AEC-Q200 and RoHS standards for quality and environmental compliance. Explore more Surface Mount Inductors and related electronic components in our catalog for industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 2.45μH with a tolerance of ±20%.
It can handle a maximum DC current of 14.1A.
The dimensions are 8.5mm in length, 5.4mm in height, and 8mm in depth.
The maximum operating temperature is 150°C.
It features a metal composite core, which enhances stability and heat resistance.
It is packaged in tape & reel format, suitable for automated PCB insertion processes.
It complies with the automotive standard AEC-Q200.
The maximum DC resistance is 8.14 milliohms.
This model features a shielded wirewound construction, which reduces electromagnetic interference.
The minimum operating temperature is -40°C.
The maximum self-resonant frequency is 100kHz.
It is suitable for applications in industrial and automotive electronics, including noise filtering and power supply regulation.
